Antiferromagnets have gained significant interest in recent years due to their potential application in antiferromagnetic spintronic devices and neuromorphic computing where the antiferromagnet is the active element. A current problem in the development of such devices is a lack of understanding of the magnetic properties of antiferromagnets. Atomistic modelling is a powerful tool in understanding these properties as it has the ability to model the materials in atomistic detail but on a scale comparable to realistic device sizes. Here, an atomistic model [1] is used to model the technologically relevant anti-ferromagnetic material Iridium Manganese to calculate the ground state spin structure and magnetic anisotropy. Previously, only the properties of fully ordered Iridium Manganese alloys or disordered IrMn3 have been investigated due to the complex material anisotropy of disordered crystal structures. Here, we have overcome this problem by modelling the anisotropy using the Néel pair anisotropy model which has the capability to accurately model any order or composition of IrMn [2]. Initially, the model was validated by comparing the results for ordered and disordered IrMn3, against previous experimental and theoretical calculations. The properties of never before theoretically studied compositions and orders of IrMn were calculated with particular focus on the technologically relevant compositions close to IrMn4 - IrMn5 used in realistic devices. It was found that all the technologically relevant alloys of disordered IrMn have the same ground state structure. A full composition study of the fully ordered and fully disordered states was undertaken, and it was found that in both cases the Néel temperature increases as the Mn content is increased, stabilizing the spin structure. These findings are an important step towards understanding the fundamental properties of antiferromagnets for applications.References: [1] R. F.L. Evans, et al, J Phys Cond. Matter, 26, (2014) [2] S. Jenkins, et al Physical Review B, 100, (2019)

MMM 2020

Atomistic spin dynamics simulations of Iridium Manganese Alloys
