Multiferroics that show coupling between electric and magnetic properties are promising materials for devices that transform information from one state into another, such as spin excitations into charge, phonons or photons. Among them, BiFeO3 (BFO) is one of the very few compound displaying room temperature multiferroicity. BFO leads for example to spectacular THz electromagnetic wave generation and photostriction properties. The prospects for applications in this area such as optically triggered piezotransducers require a perfect knowledge of the elastic properties of materials. Combining Time Resolved Acoustic Measurements (TRAM) with density functional theory (DFT) calculations and volumic and surface mode propagations simulations, we have studied the elastic properties of BiFeO3. Using TRAM, we have measured wave propagation along 3 differents directions in the (110) plane of BFO. Then, we determined three modes speeds : one longitudinal mode, one fast and one slow transverse modes. With DFT, we calculated a set of elastic constants for BiFeO3. We used these elastic constants to simulate the propagation of volumic and surface modes. The comparison between the calculated and measured speeds enables to ajust the elastic constants. In conclusion, we have been able to fully determine the elastic constant of BiFeO3 that are essential for future integration of BFO in acoustic micro/nano-devices.
