Rubber bands can be found in many children’s toys. For example, one winds up a rubber band and when released it drives an airplane or a racing car. If instead we wind up a tiny magnetic structure, where the magnetization twists and stores energy, then that energy will be released upon unwinding. In this theoretical work we consider a very soft, low-exchange film (80-400 atomic layers of Cu-doped Permalloy [1]), which is pinned at the bottom and coupled to a high-exchange ferromagnetic film on top. We apply a magnetic field which is rotated in the plane of the film. This generates a slow twisting of the soft material with the high-exchange ferromagnet acting as a handle as is seen in Fig. 1. We use both a local self-consistent mean-field theory [2] as well as a dynamic approach with the Landau-Lifshitz equation, with results matching well for both. With these models we have been able to generate multiple twists (over 10) in these films. At some point an instability occurs that prevents additional twists. Often the instability causes one or more twists to be released from the structure. The tightness of the twists as well as how many twists are formed before snapping depends on the length of the structure, the strength of the applied field, the size of the of the ferromagnetic cap, the exchange coupling strength, and the saturation magnetization. For example, increasing the exchange coupling decreases the number of twists that are stable in a given structure. The number of allowed twists also increases linearly with the length of the sample. Analytic energy minimization calculations, using a constant turn angle approximation, also allow us to estimate how many twists will fit into a given structure, matching reasonably well with numerical outcomes. The more twists in a given structure, the more energy it can hold. Once the twist is released or snapped, the system will unwind with frequencies in the gigahertz range. We study the frequency distribution as a function of the number of twists. Based on energy storage and this frequency generation we discuss potential applications.References: [1] N. Sorensen, R. E. Camley and Z. Celinski, J.Magn Magn Mat, vol. 477, p. 344, (2019). [2] R. E. Camley, Phys Rev B, vol. 35, p. 3608, (1987).

MMM 2020

Mini Magnetic Propellers: Stability Considerations in Twisted Magnetic Structures
