Hexagonal ferrite materials such as BaFe12O19 and SrFe12O19 have strong anisotropic magnetic field and strong remnant magnetism. These properties enable the working frequency of devices such as phase shifter, isolator and circulator, move up to tens of GHz without a strong external bias field and even achieve self-biasing. Other features such as large saturation magnetization, large anisotropy, and low dielectric loss and most importantly, its potential of achieving self-bias, paves the way to fabrication of planar ferrite device that can play a crucial role in a next generation wireless system. The advantage of ferrite devices are their low insertion loss, high isolation, broad bandwidth and high power handling ability compared to their active counterparts. If the fabrication process of aforementioned devices can be integrated into the mature CMOS process flow as an option, it will gain great competiveness as regards the cost. In this work, thin film ferrite material was deposited by employing spin-casting method [Liu 2013] and patterned with the help of Chemical-Mechanical Polishing (CMP). The spin-casting is a low-temperature process: the nano-sized barium ferrite materials can be processed into composite and spin-casted into thin film layer. This method requires only 120°C baking under external biasing filed. In this research, we present the design, simulation, fabrication and measured results of a self-bias micro-strip line Barium hexagonal Nano-ferrite (BaM) circulator on silicon wafer as Fig. 1. This planar Y-junction circulator is 2mm by 2mm by 0.5mm in size, which is capable of future integration with the top three layers of 180nm CMOS technology. Ferrite thin film is deposited and patterned employing composite spin-casting method. Typical characterization techniques are employed together with free-space quasi-optical spectrometry to study complex permittivity and permeability of deposited film up to 120GHz. S parameters of fabricated circulators are characterized by a set of on wafer probes up to 67GHz as Fig. 2. We observed over 15dB non-reciprocal phenomenon at 55GHz.References: Liu C, Sholiyi O, Afsar M N and Williams J D (2013), “Characterization of micro-structured ferrite materials: course and fine barium, and photoresist composite,” Magnetic, IEEE Transactions on, vol. 49, pp.4319-4322, July 2013.

MMM 2020

Hexagonal Nano-ferrites used on a V-band Self-bias On-chip Circulator for CMOS
