A 14-bits cyclic ADC is implemented in two-tier 3D sequential integration
(3DSI) multi-process technology. The ADC specifications are intended
for the daughter-payloads of the investigation of cusp irregularities (ICI) sounding
rocket series, i.e. small sensor platforms that are ejected in-flight to measure
plasma electron density in a cloud around the rocket. The two 3DSI processes
used are a 65nm SOI technology with 28nm shrink transistors in the top tier
and 28nm FDSOI as the bottom tier. This work aims to explore architectures
in a high-density interconnect 3D sequential integration process for area and
power reduction, exploiting fine-grained transistor placement as well as device
parameter optimization having the choice of two different CMOS technologies
for each individual device.
