Magnetic materials showing perpendicular magnetic anisotropy (PMA) and low damping are of great importance in spintronics. Co/Ni multilayers have been known to exhibit large tunable PMA [1], high spin polarization [2] and relatively low intrinsic damping [3]. In this study we investigated a series of Pt/[Co/Ni]N/Ir multilayers grown on Si/SiO2 with a Ta/Pt seed adhesion layer and the multilayer stack was capped with an Ir/Pt/Ta capping layer. Broadband ferromagnetic resonance (FMR) and polar angle dependent FMR measurements reveal the presence of a strong fourth-order contribution to the perpendicular anisotropy. Polar angle dependent data are fitted using the Smit-Beljers relation [4] to extract both the second and fourth-order anisotropy constants (shown in Fig.1). This model explains the data qualitatively and we observe systematic deviations for samples near or in the easy cone state of the phase diagram. We find that the effective Gilbert damping scales with the inverse multilayer thickness, indicating a significant interfacial contribution to the damping process.References: 1. G. Daalderop, P. Kelly and F. D. Broeder, Physical Review Letters., vol 68, p:682-685 (1992) 2. S. Mangin, D. Ravelsona, J. A. Katine, et.al., Nature Materials., vol 5, p:210-215 (2006) 3. J. M. Shaw, H. T. Nembach and T. J. Silva, Journal of Applied Physics., vol 108, p: 093922 (2010) 4. J. Smith and H. Beljers, Philips Research Reports., vol 10, p:113 (1955)



MMM 2020

Higher-order contribution to perpendicular anisotropy and interfacial damping of Co/Ni multilayers
