This work describes a technique for 3D printing of magnetic materials at millimeter and sub-millimeter scales for microrobotic applications using stereolithography. Traditional fabrication techniques to engineer magnetic materials become very challenging at smaller scales. The need for rapid prototyping techniques using materials with tunable magnetic properties is becoming more important [1]. Unfortunately, additive manufacturing of magnets is still in its infancy [2-3]. Most reported techniques that are based on thermoplastic bonded magnets [4-5], filament extrusion [6], binder jetting [7], or laser sintering [8], have limitations for scaling down in size. A better path towards miniaturization is offered by stereolithography [9], as presented in this work. The presented technique combines magnetic particles (NdFeB, Fe or Fe3O4) with different mixing ratios to a flexible resin that is made from aliphatic urethane diacrylate, epoxy aliphatic acrylate and a photo-initiator (Irgacure 819 - Irgacure 184) [10]. 3D printed multi-material structures are presented in Fig. 1a. This work is motivated by the need to engineer complex magnetic field patterns for MEMS actuators [11-12] and micro/soft robotics (Fig. 1B) [13]. Magnetic moment was measured to evaluate dependence of saturation magnetization and coercivity with particle material and particle concentration (Fig. 2a). Torques and forces over printed samples were measured in response to external magnetic fields (Fig. 2b), demonstrating an ability to generate highly complex 3D structures for actuation at micro- to meso-scales.References: [1] G. Chatzipirpiridis et al., “3D Printing of Thermoplastic Bonded Soft and Hard Magnetic Composites: Magnetically Tuneable Architectures and Functional Devices,” Adv. Intell. Syst., vol. 1, no. 6, p. 1900069, 2019. [2] L. Li, B. Post, V. Kunc, A. M. Elliott, and M. P. Paranthaman, “Additive manufacturing of near-net-shape bonded magnets: Prospects and challenges,” Scr. Mater., vol. 135, pp. 100–104, Jul. 2017. [3] V. Popov, A. Koptyug, I. Radulov, F. Maccari, and G. Muller, “Prospects of additive manufacturing of rare-earth and non-rare-earth permanent magnets,” Procedia Manuf., vol. 21, no. March, pp. 100–108, 2018. [4] L. Pigliaru et al., “3D printing of high performance polymer-bonded PEEK-NdFeB magnetic composite materials,” Funct. Compos. Mater., vol. 1, no. 1, p. 4, Dec. 2020. [5] P. P. Wendhausen, C. H. Ahrens, A. B. Baldissera, P. D. Pavez, and J. M. Mascheroni, “Additive manufacturing of bonded NdFeB, process parameters evaluation on magnetic properties,” in 2017 IEEE International Magnetics Conference (INTERMAG), 2017, vol. 53, no. 11, pp. 1–1. [6] B. Khatri, K. Lappe, D. Noetzel, K. Pursche, and T. Hanemann, “A 3D-Printable Polymer-Metal Soft-Magnetic Functional Composite—Development and Characterization,” Materials (Basel)., vol. 11, no. 2, p. 189, Jan. 2018. [7] C. L. Cramer et al., “Binder jet additive manufacturing method to fabricate near net shape crack-free highly dense Fe-6.5 wt.% Si soft magnets,” Heliyon, vol. 5, no. 11, p. e02804, Nov. 2019. [8] C. V. Mikler et al., “Laser Additive Manufacturing of Magnetic Materials,” JOM, vol. 69, no. 3, pp. 532–543, Mar. 2017. [9] L. Lu, P. Guo, and Y. Pan, “Magnetic-Field-Assisted Projection Stereolithography for Three-Dimensional Printing of Smart Structures,” J. Manuf. Sci. Eng., vol. 139, no. 7, pp. 1–7, Jul. 2017. [10] D. K. Patel, A. H. Sakhaei, M. Layani, B. Zhang, Q. Ge, and S. Magdassi, “Highly Stretchable and UV Curable Elastomers for Digital Light Processing Based 3D Printing,” Adv. Mater., vol. 29, no. 15, p. 1606000, Apr. 2017. [11] A. P. Taylor, C. Velez Cuervo, D. P. Arnold, and L. F. Velasquez-Garcia, “Fully 3D-Printed, Monolithic, Mini Magnetic Actuators for Low-Cost, Compact Systems,” J. Microelectromechanical Syst., vol. 28, no. 3, pp. 481–493, Jun. 2019. [12] Y. Kim, G. A. Parada, S. Liu, and X. Zhao, “Ferromagnetic soft continuum robots,” Sci. Robot., vol. 4, no. 33, p. eaax7329, Aug. 2019. [13] J. J. Abbott, E. Diller, and A. J. Petruska, “Magnetic Methods in Robotics,” Annu. Rev. Control. Robot. Auton. Syst., vol. 3, no. 1, pp. 57–90, May 2020.

MMM 2020

Multimaterial and flexible 3D printed magnets with sub-millimeter resolution

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


technical paper

Cylindrical magnetic nanowires (CNWs) are promising candidates for the building blocks of 3D information technologies such as shift registers, magnetic recording, spintronics and logic gates1-4. Spin-polarized-current is an energy efficient way to excite magnetization dynamics in planar nanostructures. However, in CNWs this research is doing its first steps5. Magnetization dynamics in a CNW of Permalloy, 100 nm diameter and 1 µm length, is investigated under simultaneous application of electric current and magnetic field by micromagnetic simulations. The magnetization reversal process initiates with the creation of open vortex structures with different rotation senses at the nanowire ends. We conclude that the electric current by itself enlarges or reduces the length of these vortex structures according to the rotational sense of the associated Oersted field. Large enough current densities produce a vortex structure which covers the whole nanowire surface. At the same time, the magnetization in the very core of the nanowire remains the same, i.e. no complete magnetization reversal is possible in the absence of external magnetic field. The simultaneous action of the applied electric current and magnetic field allows the complete control of the vortex structures in terms of setting the polarity and vorticity. The resulting diagram of magnetic states obtained after the application of field and electric current showing the values required for the vorticity and axial magnetization switching is presented in Figure 1. This control is essential for future information technologies based on 3D vertical nanostructures. The presented state diagram will become useful for future experiments on current-induced domain wall dynamics in CNWs.References: 1. S. Parkin and S.-H. Yang, Nature Nanotechnology., Vol. 10, pp. 195 (2015). 2. F. Nasirpouri, et al., Scientific Reports., Vol. 9, pp. 9010 (2019). 3. S. Ruiz-Gómez et al., Scientific Reports., Vol. 8, pp. 16695 (2018). 4. J. Garcia et al., Journal of Magnetism and Magnetic Materials., Vol. 383, pp. 88 (2015). 5. M. Schöbitz et al., Physical Review Letters Vol. 123, pp. 217201 (2019).

Control of Vortex Structures in Individual Cylindrical Magnetic Nanowires by Simultaneous Action of Applied Magnetic Field and an Electric Current

The behavior of any physical system is governed by the order parameter, determined by the geometry of the physical space of the object, namely their dimensionality and curvature. Usually, the effects of curvature are identified using local interactions only, e.g. local spin-orbit- or curvature-induced Rashba and Dzyaloshinskii-Moriya interactions in condensed matter [1]. Lack of the framework, involving both, local and non-local interactions impedes the description of the essentially micromagnetic textures like magnetic domains, skyrmion-bubbles and vortices. Here, we present a micromagnetic theory of curvilinear ferromagnetic shells [2]. New chiral effects, originating from the magnetostatic interaction, can appear in such systems. They manifest themselves even in statics and are essentially nonlocal. This is in contrast to conventional Dzyaloshinskii--Moriya interaction (material intrinsic or curvature-induced, stemming from the exchange). The physical origin is in a non-zero mean curvature of a shell and non-equivalence between the top and bottom surfaces of the shell. To describe the new effects, we split a conventional volume magnetostatic charge into two terms: (i) magnetostatic charge, governed by the tangent to the sample's surface, and (ii) geometrical charge, given by the normal component of magnetization and the mean curvature. We classify the interplay between the symmetry of the shell, its local curvature and magnetic textures and apply the proposed formalism to analyze magnetic textures in corrugated shells with perpendicular anisotropy.References: [1] R. Streubel, J. Lee, D. Makarov et al, J. Phys. D, 49, 363001, (2016); [3] O. V. Pylypovskyi, D. D. Sheka, V. P. Kravchuk et al, Sci. Rep. Vol. 6, p. 23316 (2016); O. M. Volkov, D. D. Sheka, Y. Gaididei et al, Sci. Rep. Vol. 8, p. 866 (2018). [2] D. D. Sheka, O. V. Pylypovskyi, P. Landeros et al., Comm. Phys. 3, 128 (2019), DOI:10.1038/s42005-020-0387-2

Magnetostatics-Induced Symmetry Breaking Effects in Curvilinear Shells

Ferromagnetic nanotubes generate continuous interest due to non-collinear spin structures which are tailored by the curvature of the ferromagnetic film [1]. If arranged vertically on a chip [2], they allow for high-density arrays and 3D device architectures in spintronics and magnonics. For their realization, coating of filamentary nanotemplates would be advantageous. However, conformal deposition of ferromagnetic metals is still a challenge. We report the fabrication of Ni nanotubes by atomic layer deposition (ALD) applied to single-crystalline semiconductor nanowires. We used nickelocene as a precursor, water as the oxidant agent and an in-cycle plasma enhanced reduction step with hydrogen. The optimized ALD pulse sequence, combined with a post-processing annealing treatment, allowed us to prepare 30 nm thick metallic Ni layers with a low resistivity of 8 μΩcm at room temperature and good conformality both on the planar substrates and nanotemplates [3]. We prepared several micrometer-long Ni nanotubes with diameters ranging from 120 to 330 nm. We report on the correlation between ALD growth and functional properties of individual Ni nanotubes characterized in terms of magneto-transport at room temperature and the confinement of spin wave modes explored by micro-focus Brillouin light scattering. For the relative variation of resistance R of a nanotube in small magnetic fields we find a value of up to 1.3 % which we attribute to the anisotropic magnetoresistance (AMR) effect. This value is larger by about 30 % compared to the best low-field AMR effect of Ni nanotubes studied previously [4,5]. In the ALD process applied to semiconductor nanowires in Refs. [4,5] the plasma enhancement of the hydrogen reduction step was not available. Together with the spin-wave resonances observed in the Ni nanotubes our findings promise Ni-based 3D device architectures for spintronic and magnonic devices prepared by ALD and operated in the GHz frequency regime. Funding by the German Science Foundation DFG via GR1640/5-2 in SPP1538 Spin caloric transport and SNF via grants 163016, BSCGI0157705, and NCCR QSIT is gratefully acknowledged.References: [1] R. Streubel, P. Fischer, F. Kronast et al., J. Phys. D: Appl. Phys., Vol. 49, p. 363001 (2016). [2] Y.-P. Wang, Z.-J. Ding, Q.-X. Liu et al, J. Mater. Chem. C, Vol. 4, p. 11059 (2016). [3] M.C. Giordano, K. Baumgaertl, S. Escobar Steinvall et al., ACS Appl. Mater. Interfaces (2020), https://doi.org/10.1021/acsami.0c06879. [4] D. Rüffer, R. Huber, P. Berberich et al., Nanoscale, Vol. 4, p. 4989 (2012). [5] D. Rüffer, M. Slot, R. Huber et al., APL Mater., Vol. 2, p. 076112 (2014).

Nickel nanotubes with low resistivity and coherent magnetization dynamics for 3D spintronics and magnonics prepared by atomic layer deposition

The structural inversion symmetry plays an important role in low-dimensional nanomagnets, due to its strong influence on magnetic and electrical properties. It can lead to the appearance of chiral effects, such as the topological Hall effect [1], or to the formation of chiral noncollinear magnetic textures, as skyrmions [2] and chiral domain walls (DWs) [3]. These chiral structures can be the key components for realizing novel concepts for magnonics [4], antiferromagnetic spintronics [5], spin-orbitronics [6], and oxitronics [7]. So far, the main chiral symmetry breaking effect considered as being the origin for the presence of chiral noncollinear magnetic textures is the intrinsic Dzyaloshinskii-Moriya interaction (DMI) [8,9], which appears in certain magnetic crystals in which the unit cell lacks inversion symmetry, such as the gyrotropic magnetic crystals, or appear typically in ultrathin films or bilayers due to the inversion symmetry breaking on the film interface [3]. At present, tailoring of DMI is done by optimizing materials, either doping a bulk single crystal or adjusting interface properties of thin films and multilayers. A viable alternative to the conventional material screening approach can be the exploration of the interplay between geometry and topology. This interplay is of fundamental interest throughout many disciplines in condensed matter physics, including thin layers of superconductors [10] and superfluids [11], nematic liquid crystals [12], cell membranes [13], semiconductors [14]. In the emergent field of curvilinear magnetism chiral effects are associated to the geometrically broken inversion symmetries [15]. Those appear in curvilinear architectures of even conventional materials. There are numerous exciting theoretical predictions of exchange- and magnetostatically-driven curvature effects, which do not rely on any specific modification of the intrinsic magnetic properties, but allow to create non-collinear magnetic textures in a controlled manner by tailoring local curvatures and shapes [16,17]. Until now the predicted chiral effects due to curvatures remained a neat theoretical abstraction. Very recently, we provided the very first experimental confirmation of the existence of the curvature-induced chiral interaction with exchange origin in a conventional soft ferromagnetic material. It is experimentally explored the theoretical predictions, that the magnetisation reversal of flat parabolic stripes shows a two step process [18,19]. At the first switching event, a domain wall pinned by the curvature induced exchange-driven DMI is expelled leading to a magnetisation state homogeneous along the parabola's long axis. Measuring the depinning field enables to quantify the effective exchange-driven DMI interaction constant. The magnitude of the effect can be tuned by the parabola's curvature. It is found that the strength of the exchange-induced DMI interaction for the experimentally realised geometries is remarkably strong, namely ~0.4 mJ/m2, compared the surface induced DMI. The presented study legitimates the predictive power of full-scale micromagnetic simulations to design the properties of ferromagnets through their geometry, thus stabilising chiral textures. We explore these curvilinear magnetic thin films for the realization of novel artificial magnetoelectric materials based on curvilinear helimagnets embedded in piezoelectric matrix [20], to enable the geometrical tuning of the magnetochirality in curvilinear 1D architectures [21], tailoring of magnetic states in flat nanospirals [22] and as components of shapeable magnetoelectronics for interactive wearables [23].References: [1] N. Nagaosa, et al., Nature Nanotech. 8, 899 (2013) [2] U. K. Rößler, et al., Nature 442, 797 (2006) [3] A. Fert, et al., Nature Rev. Mat. 2, 17031 (2017) [4] A. V. Chumak, et al., Nature Physics 11, 453 (2015) [5] T. Jungwirth, et al., Nature Nanotech. 11, 231 (2016) [6] I. M. Miron, et al., Nature 476, 189 (2011) [7] V. Garcia, et al., Nature 460, 81 (2009) [8] I. Dzyaloshinsky, J. Phys. Chem. Solids 4, 241 (1958). [9] T. Moriya, Phys. Rev. Lett. 4, 228 (1960). [10] J. Tempere, et al., Phys. Rev. B 79, 134516 (2009) [11] H. Kuratsuji, Phys. Rev. E 85, 031150 (2012) [12] T. Lopez-Leon, et al., Nature Physics 7, 391 (2011) [13] H. T. McMahon, et al., Nature 438, 590 (2005) [14] C. Ortix, Phys. Rev. B 91, 245412 (2015) [15] Y. Gaididei, et al., Phys. Rev. Lett. 112, 257203 (2014) [16] J. A. Otálora, et al., Phys. Rev. Lett. 117, 227203 (2016) [17] V. P. Kravchuk, et al., Phys. Rev. Lett. 120, 067201 (2018) [18] O. Volkov et al., PRL 123, 077201 (2019). [19] O. Volkov et al., PSS-RRL 13, 1800309 (2019). [20] O. Volkov et al., J. Phys. D: Appl. Phys. 52, 345001 (2019). [21] O. Volkov et al., Scientific Reports 8, 866 (2018). [22] M. Nord, et al., Small 1904738 (2019). [23] J. Ge, et al., Nature Comm. 10, 4405 (2019).

Curvature-driven Chiral Effects in Nanomagnetism INVITED

The discovery of chiral spin textures such as domain walls, skyrmions, merons and bobbers, with their associated non-trivial topology and superior spintronic properties, is one of the most exciting landmarks in nanomagnetism and spintronics in recent years. Until now, these spin textures have been mostly realised by exploiting symmetry-breaking effects in non-centrosymmetric bulk crystals and synthetic ultra-thin film heterostructures. An emerging alternative route to the generation of chiral spin interactions is geometry [1]. In thin films, for example, curvature can provide the breaking of inversion-symmetry necessary for the generation of localized DMI-like spin interactions [2]. In this work, we employ state of the art 3D nanofabrication [3] to demonstrate the generation of complex chiral spin states using only geometrical effects, with no special material requirements. To do so, we fabricate an artificial magnetic double-helix system (Figure 1a) and perform magnetic X-ray microscopy [4]. This nanostructure is formed by two strongly-interacting strands (Figure 2) with dimensions comparable to fundamental magnetic lengths. By designing geometrical chirality, a wide variety of complex chiral 3D states is imprinted into the internal magnetization vector field. This includes helical magnetic domain walls (Figure 1b), vortex tubes and topologically-induced point-like structures [4]. In this presentation we will describe in detail how the topological mismatch caused by matching a left-handed and a right-handed double helix (See * in Figure 1a) leads to the generation of a localized Néel defect and the formation of an asymmetric vortex state [4]. These results showcase the power of using geometry for the localized generation of complex spin states, opening new paths for the study of non-trivial spin textures.References: [1] Streubel, R. et al. Journal of Physics D: Applied Physics 49.36 (2016): 363001. [2] Kravchuk, V. P., et al. Physical review letters 120.6 (2018): 067201. [3] Skoric, L. et al. Nano Letters 20.1 (2019): 184-191. [4] Sanz-Hernández, D., et al. arXiv:2001.07130 [cond-mat.mes-hall]

Creating and Interfacing Chiral Spin Textures Using 3D Geometries INVITED

When applied to C2V ferromagnetic/heavy metal interfaces, Moriya’s rules do not deterministically predict the orientation of interatomic DM vectors. Low-symmetry magnetic systems can exhibit both Rashba (DR) and Dresselhaus (DD) forms of the Dzyaloshinskii-Moryia interaction (DMI), as both spin-orbit couplings are generally present [1]. We assert that the spatial variation of the DM vectors—and thus that of the strength and direction of the effective DMI field—is determined by the DMI’s character (i.e., ||DD||/||DR||), as well as the unit cell’s aspect ratio [2]. Overall, the DMI is thus nominally anisotropic and hybridized—potentially stabilizing antiskyrmions and Bloch-Néel (i.e. mixed) skyrmions [2-3]. Ascertaining the existence and tunability of [anti]skyrmions in such systems is of technological interest and would elucidate the nature of DMI [2]. Employing the Wulff construction [3], ξ-vector formalism [4], and an augmented wall energy that accounts for DMI character, this work models the equilibrium shape and wall magnetization profile of bubble domains and skyrmions in thin films with C2v symmetry. We show that for sufficiently large DMI, square-shaped antiskyrmions are stable for certain DM vector orientations while lens- and oval-shaped mixed skyrmions are favored otherwise. A symmetry-breaking applied in-plane field stabilizes domain shapes resembling ovals and Reuleaux triangles. The impact of the unit cell’s aspect ratio, the DM vector’s orientation, and other material parameters on the shape of bubble domains and skyrmions are discussed. Moreover, our results reveal unusual relationships between faceting behavior and wall stiffness under rather reasonable conditions. Elucidating the interplay between the different effective fields present, we explore the validity of these results based on pedal plots, discontinuities in the magnetization profiles, and local extrema in the wall energy.References: U. Güngördü et al., Physical Review B., 93, 064428 (2016) M. Hoffman et al., Nature Communications., 8, 308 (2017) J. P. Pellegren, D. Lau, and V. Sokalski, Physical Review Letters., 119, 027203 (2017) A. A. Wheeler, Journal of Statistical Physics., 95, 1245–1280 (1999)

Energetics, equilibrium shape, and vorticity of skyrmions and antiskyrmions stabilized by the anisotropic Dzyaloshinskii-Moriya interaction in thin films with C2v symmetry

New fascinating phenomena involving coupled spin waves and phonons are observed at the magneto-elastic resonance: magnetic field dependent spin Seebeck effect [1], acoustically-assisted spin pumping [2, 3] and magnetization swiching [4, 5]. In this context, it has been shown that an efficient mean to excite phonons is by surface acoustic waves (SAW). The integration of SAW-FMR (ferromagnetic resonance) mechanism in spintronic and magnonic devices are claimed to operate with very low power. However, most ferromagnetic materials have precession frequencies well above 5 GHz, i.e. above the highest frequency reached by today's SAW technologies. This restricts the research on SAW-FMR to low magnetization and/or low magnetic anisotropy materials, such as (Ga,Mn)As or (GaMn)(As,P), Ni, and YIG. Here, we show that thin films of Fe epitaxially grown on GaAs(001), a spintronic and magnonic compatible magnetoelastic and piezoelectric heterostucture, give the opportunity to obtain SAW-FMR, at room temperature, below 1 GHz despite the high Fe magnetization. This is obtained by exploiting the softening of the magnetic stiffness when the field is applied along a hard axis, at moderate intensity (60 mT). Slight variations of the magnetic field direction, less than 0.1 deg off, increase dramatically magnetization precession frequency leading to off-resonance interaction and suppressing SAW attenuation. The observed phenomena are described by adopting a very simple magnetization dynamics model that catches the physics of the interaction. The observation of resonant, low frequency and highly directional magnetoelastic coupling in Fe suggests that SAW mature technology offers the opportunity to magnonics and spintronics to handle magnetization precession in a remote way, without using any dissipative electron current. [6]References: [1] Takashi Kikkawa, et al., Phys. Rev. Lett. 117, 207203, (2016) [2] M. Weiler, et al. Phys. Rev. Lett. 108, 176601, (2012) [3] Ken ichi Uchida, et al., Solid State Communications 198, 26, (2014) [4] L. Thevenard,et al. Phys. Rev. B 93, 134430, (2016) [5] P. Kuszewski, et al. Journal of Physics: Condensed Matter 30, 244003 (2018) [6] J.-Y. Duquesne, P. Rovillain, et al. Phys. Rev. Appl. 12, 024042 (2019)

Sub-GHz resonant magnetoelastic coupling in epitaxial Fe thin films

Voltage control of the structure, magnetic and electronic properties of materials enables the realization of new types of nonvolatile magnetoelectric memory devices. Here, we investigate the effect of ionic liquid gating on the magnetic properties of self-assembled heterostructure films consisting of nanoscale CoyFe3-yO4 (CFO) spinel pillars embedded in a SrCo1-xFexO3-δ (SCFO) perovskite (P) or brownmillerite (BM) matrix, over a range of compositions x and y. These self-assembled nanocomposites are grown by pulsed laser deposition on SrTiO3 substrates using SrCoO3-δ-SrFeO3-δ, SrCoO3-δ-Fe3O4, or SrFeO3-δ-Co3O4 pairs of targets. We first describe the growth kinetics of these nanocomposites, focusing on how the oxygen pressure affects the distribution of Co and Fe between the two phases and the formation of P vs. BM structure for the matrix. Unusually, at high oxygen pressures, the two-phase structure can grow from the codeposition of SrCoO3-δ and SrFeO3-δ, attributed to depletion of the Sr in the film. The pillar CFO magnetism depends on y, e.g. ferrimagnetic with room temperature saturation magnetization Ms ~300 kA/m for y=1 and paramagnetic for y=0. The matrix SCFO with the BM phase has antiferromagnetic ordering irrespective of x, while the magnetism of the P phase depends strongly on x and can exhibit a room temperature Ms ~100 kA/m for x=0.5 but almost no moment for x=0 and x=1 [1]. With the gating voltage of -3V/+3V, the lattice parameter of matrix SCFO changes ±3% and induces strain transfer around ±1% to the pillar phase (Fig. 1). In particular, for x=0.5 and y=0 (Fig. 2), the negative gating inserts oxygens into the BM phase and changes it into a P phase showing ferromagnetism. Our study clarifies the manipulation of the magnetism of composite materials through an electrochemical process, expanding the applications of magnetoelectric coupling.References: [1] S. Ning, Q. Zhang and C. A. Ross, ACS Nano, https://dx.doi.org/10.1021/acsnano.0c03750 (2020)

Controlling Magnetic Properties of Epitaxial Nanocomposite Thin Films Through Ionic Liquid Gating

The focus of lab-on-a-chip technology centers on small, low power devices that can be integrated on a microscopic scale to perform laboratory functions within one unit or “chip”. In order to achieve this, one has to understand how to transfer fluid at this scale. Due to the low Reynolds number limit, such devices need to break time-reversible symmetry to produce a net flow. There has been a degree of interest and research into using magnetic materials to achieve this. In this work, we propose a new model employing ferromagnetic elements for construction of a practical microfluidic pump. The design is based on a repeated chain of magnetic discs connected together via links with hinges at the centers of the discs, which allow the discs to rotate (Fig 1a). While the model is based on that of ferromagnetic swimmers[1]. The device is surrounded by fluid and is activated by an external AC magnetic field. The magnetic and elastic forces in this device can work together against the fluidic forces to create a time-irreversible movement, which results in a net flow. While magnetisation of all the discs are oriented in the same direction, the relative rotational stiffness of the discs (or hinge stiffness) is varied to produce a lag in the response to the magnetic torque. This collective effect is similar to that of a metachronal wave, which is ultimately responsible for the flow. We found that if both discs had the same rotational stiffness, then no flow was produced. Depending on the chosen frequency, there is an optimal rotation stiffness of the two discs where a maximum flow rate is achieved. We observed as the frequency increases so does the flow, until the frequency is too large for the discs to turn to their maximum angle before the direction of the magnetic field reverses. To conclude, we demonstrated that an elasto-magnetic device can produce a net flow at low Reynolds number. The flow direction can be controlled by altering the frequency of the driving magnetic field or by using different rotational stiffness. These results could lead to new types of ferromagnetic pumping devices.References: [1] A. D. Gilbert, et al., Q. J. Mech. Appl. Math., 64, 239 (2011).
