**Abstract:**

This paper provides guidelines to design porous silicon layers regarding optimization of small-signal properties in passive structures for RF: insertion loss and cross talk. Results are based on high frequency measurements on 200 mm wafers and electromagnetic simulations up to 40 GHz. Using substrate resistivity below 1 ohm.cm allows the best trade-off with minimized porous silicon thickness.

ESSCIRC ESSDERC 2021

Influence of Substrate Resistivity on Porous Silicon Small Signal RF Properties

substrate resistivity

s-parameters

porous silicon (ps)

linear attenuation coefficient

crosstalk
