This paper investigates how various caching strategies can reduce the computational effort of the active set method (ASM) applied to solve constrained model predictive control problems with quadratic objective function and linear constraints. Specifically, we show that during closed-loop operation, the active set method often re-visits the same combination of active constraints while searching for optimal control inputs by factoring Karush-Kuhn-Tucker (KKT) systems. By storing the factors of the corresponding KKT system in a cache, these repetitive

Nonlinear Model Predictive Control Conference 2021

Streamlining Active Set Method in MPC Using Cache Memory

model predictive control

active set method

cache replacement policies

cache memory

The IFAC Conference on Nonlinear Model Predictive Control (NMPC 2021) aims to bring together researchers interested in and work in the MPC field from both academia and industry. This allows us to reflect and establish the current state-of-the-art and focus on the future development of the MPC field towards relevant directions.

Model predictive control (MPC) is indisputably one of the advanced control techniques that have significantly affected control engineering practice with thousands of controllers implemented in various fields, spanning from the process industry to automotive and robotics. This is due to its unique ability to handle constraints, take preview information about disturbances and setpoint changes into account, and optimize performance. Furthermore, MPC allows the consideration of various types of dynamics, from linear to nonlinear, discrete to continuous, as well as an online adaptation of models and parameters. The research community on MPC is very active, with hundreds of papers published every year. Over the past decades, many theoretical, as well as implementation results, have been achieved.
