We present a model predictive control (MPC) scheme to control linear time-invariant systems using only measured input-output data and no model knowledge. The scheme includes a terminal cost and a terminal set constraint on an extended state containing past input-output values. We provide an explicit design procedure for the corresponding terminal ingredients that only uses measured input-output data. Further, we prove that the MPC scheme based on these terminal ingredients exponentially stabilizes the desired setpoint in closed loop. Finally, we illustrate the advantages over existing data-driven MPC approaches with a numerical example.

Nonlinear Model Predictive Control Conference 2021

On the Design of Terminal Ingredients for Data-Driven MPC

stability and recursive feasibility

output feedback predictive control

learning and predictive control

The IFAC Conference on Nonlinear Model Predictive Control (NMPC 2021) aims to bring together researchers interested in and work in the MPC field from both academia and industry. This allows us to reflect and establish the current state-of-the-art and focus on the future development of the MPC field towards relevant directions.

Model predictive control (MPC) is indisputably one of the advanced control techniques that have significantly affected control engineering practice with thousands of controllers implemented in various fields, spanning from the process industry to automotive and robotics. This is due to its unique ability to handle constraints, take preview information about disturbances and setpoint changes into account, and optimize performance. Furthermore, MPC allows the consideration of various types of dynamics, from linear to nonlinear, discrete to continuous, as well as an online adaptation of models and parameters. The research community on MPC is very active, with hundreds of papers published every year. Over the past decades, many theoretical, as well as implementation results, have been achieved.
