Cells within the same battery pack age unequally fast due to the non-uniform manufacturing process, and inhomogeneous operating conditions, and environment. This paper proposes a nonlinear Model Predictive Control approach for optimal pack balancing while taking pack and cell limitations into account. The control is designed for a sophisticated battery pack, which is a pack augmented by semiconductor switches to vary the number of cells connected in series. This pack is usually composed of more cells than a conventional battery pack. Each serial cell in the pack can be activated or deactivated while keeping the serial connection. Simulation results based on a realistic mission profile illustrate the effectiveness of the proposed approach by optimizing the overall performance and degradation of the battery architecture.

Nonlinear Model Predictive Control Conference 2021

Nonlinear Model Predictive Control for a Simulated Reconfigurable Battery Pack

nonlinear control systems

closed-loop control

binary control

model predictive control

li-ion batteries

modelling

combinatorial

The IFAC Conference on Nonlinear Model Predictive Control (NMPC 2021) aims to bring together researchers interested in and work in the MPC field from both academia and industry. This allows us to reflect and establish the current state-of-the-art and focus on the future development of the MPC field towards relevant directions.

Model predictive control (MPC) is indisputably one of the advanced control techniques that have significantly affected control engineering practice with thousands of controllers implemented in various fields, spanning from the process industry to automotive and robotics. This is due to its unique ability to handle constraints, take preview information about disturbances and setpoint changes into account, and optimize performance. Furthermore, MPC allows the consideration of various types of dynamics, from linear to nonlinear, discrete to continuous, as well as an online adaptation of models and parameters. The research community on MPC is very active, with hundreds of papers published every year. Over the past decades, many theoretical, as well as implementation results, have been achieved.
