Electronic structures and complex optical constants including dielectric functions, complex optical conductivities and absorption coefficients of a series of CdSe-based nanoplatelets (NPLs) films are simultaneously unveiled by spectroscopic ellipsometry techniques. Based on our experimental results, the incremental monolayer-thickness in thicker NPLs not only boosts the complex optical constants but also enhances the amplitude of coupling strength of the lowest excitonic transition mainly due to the higher inorganic volume fraction and the improved surface passivation. Overall, the broad tunability of complex optical features by simply controlling the growth of vertical thickness will pave a new path for the design of the next-generation NPLs-containing photonics devices.

MATERIALS FOR HUMANITY (MH 21)

Unraveling of Complex Optical Features of Neat Cadmium Selenide Nanoplatelets Thin Films for Next-generation Photonic Devices
