Flexible electronics are of critical importance for medical devices, portable electronics, smart textiles, energy storage, communication and sensor systems [1,2]. However, the lifetime of electronics is becoming shorter, which poses a growing ecological problem. Therefore, it is urgent and necessary to find sustainable and cost-efficient materials to replace the crude oil-derived polymers that are commonly used in flexible electronics. To this end, fish gelatin (FG) extracted from fish scales could provide an eco-friendly and biodegradable alternative to plastic for use in flexible electronics. Fish scales are inedible and malodorous kitchen waste, and &gt;2 million metric tons of fish scales are discarded each year. This talk will introduce our recent works on FG-based flexible electronics, including flexible electroluminescent devices and triboelectric nanogenerators (TENGs) [3-6]. The properties of FG films, the structure design and the performance of flexible electronic devices will be briefly discussed. These works may pave a new way to green and sustainable flexible electronics.

References
1. S. Xu, A. Jayaraman, J. A. Rogers. Skin sensors are the future of health care. Nature, 2019, 571, 319-321.
2. G.-H. Lee, H. Moon, H. Kim, G. H. Lee, W. Kwon, S. Yoo, D. Myung, S. H. Yun, Z. Bao, S. K. Hahn. Multifunctional materials for implantable and wearable photonic healthcare devices. Nat. Rev. Mater., 2020, 5, 149–165.
3. X. P. Zhang, T. Y. Ye, X. H. Meng, Z. H. Tian, L. H. Pang, Y. J. Han, H. Li, G. Lu, F. Xiu, H. D. Yu, J. Q. Liu, W. Huang. Sustainable and transparent fish gelatin films for flexible electroluminescent devices. ACS Nano, 2020, 14, 3876-3884.
4. T. F. Jiang, X. H. Meng, Z. Zhou, Y. Y. Wu, Z. H. Tian, Z. D. Liu, G. Lu, M. Eginlidil, H. D. Yu, J. Q. Liu, W. Huang. Highly flexible and degradable memory electronics comprised of all-biocompatible materials. Nanoscale, 2021, 13, 724-729.
5. Y. J. Han, Y. F. Han, X. P. Zhang, G. Lu, H. D. Yu, W. Huang. Fish gelatin-based triboelectric nanogenerator for harvesting biomechanical energy and self-powered sensing of human physiological signals. ACS Appl. Mater. Interfaces, 2020, 12, 16442-16450.
6. Q. Z. Sun, H. C. Wang, L. Wang, X. P. Yue, L. R. Zhang, G. Z. Ren, D. H. Li, Y. J. Han, L. L. Xiao, G. Lu, H. D. Yu, W. Huang. Fully sustainable and high-performance fish gelatin-based triboelectric nanogenerator for wearable movement sensing and human-machine interaction. Nano Energy, in revision.

MATERIALS FOR HUMANITY (MH 21)

Sustainable Flexible Electronics Based on Fish Gelatin

**Please view our Welcome to MH21 video.**

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1UYHV1pcz?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>


**Walkthrough Video**

Here is a Walkthrough showing how to navigate the conference and network with others

<center>
<figure class="video_container">
	 <iframe src="https://screencast-o-matic.com/watch/cr1vnrV1paE?v=6&ff=1&title=0&controls=1" width=826 height=526 frameborder="0" allowfullscreen="true"> </iframe>
</figure>
	</center>




	 Organized by

<a href="https://mrs.org.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/95d5789689d5f900b90e9fe54ea3cf0d.jpg"</a>



	 In association with

<a href="http://www.ntu.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/334cd171ad2fdee033c635b368e5e160.png"</a>
	<a href="https://www.nus.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/32e6f82c0440f7bb24c590f9f67821bd.png"</a>
		<a href="https://www.a-star.edu.sg/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/72557865b589cfa3d2a0243ffce4a270.png"</a>




	 Supported by

		 <a href="https://www.visitsingapore.com/mice/en/about-us/about-secb/">
<img src="https://assets.underline.io/uploads/markdown_image/1/image/6e679842ead62be522ba6a630b82d5c9.png"</a>

To access the MH 21 Conference, [please register](https://mh21.mrs.org.sg/event/da3f9651-429f-4763-81b2-ebd7311b6bc8/websitePage:206f7605-1731-41f9-8421-56d3890f398f)

MH 21 is arranged around 6 themes that focus attention on pressing needs that should be addressed to enhance the well-being of communities and provide a forum for presenting breakthrough discoveries.

Flexible electronics are of critical importance for medical devices, portable electronics, smart textiles, energy storage, communication and sensor systems [1,2]. However, the lifetime of electronics is becoming shorter, which poses a growing ecological problem. Therefore, it is urgent and necessary to find sustainable and cost-efficient materials to replace the crude oil-derived polymers that are commonly used in flexible electronics. To this end, fish gelatin (FG) extracted from fish scales could provide an eco-friendly and biodegradable alternative to plastic for use in flexible electronics. Fish scales are inedible and malodorous kitchen waste, and >2 million metric tons of fish scales are discarded each year. This talk will introduce our recent works on FG-based flexible electronics, including flexible electroluminescent devices and triboelectric nanogenerators (TENGs) [3-6]. The properties of FG films, the structure design and the performance of flexible electronic devices will be briefly discussed. These works may pave a new way to green and sustainable flexible electronics.

References
1. S. Xu, A. Jayaraman, J. A. Rogers. Skin sensors are the future of health care. Nature, 2019, 571, 319-321.
2. G.-H. Lee, H. Moon, H. Kim, G. H. Lee, W. Kwon, S. Yoo, D. Myung, S. H. Yun, Z. Bao, S. K. Hahn. Multifunctional materials for implantable and wearable photonic healthcare devices. Nat. Rev. Mater., 2020, 5, 149–165.
3. X. P. Zhang, T. Y. Ye, X. H. Meng, Z. H. Tian, L. H. Pang, Y. J. Han, H. Li, G. Lu, F. Xiu, H. D. Yu, J. Q. Liu, W. Huang. Sustainable and transparent fish gelatin films for flexible electroluminescent devices. ACS Nano, 2020, 14, 3876-3884.
4. T. F. Jiang, X. H. Meng, Z. Zhou, Y. Y. Wu, Z. H. Tian, Z. D. Liu, G. Lu, M. Eginlidil, H. D. Yu, J. Q. Liu, W. Huang. Highly flexible and degradable memory electronics comprised of all-biocompatible materials. Nanoscale, 2021, 13, 724-729.
5. Y. J. Han, Y. F. Han, X. P. Zhang, G. Lu, H. D. Yu, W. Huang. Fish gelatin-based triboelectric nanogenerator for harvesting biomechanical energy and self-powered sensing of human physiological signals. ACS Appl. Mater. Interfaces, 2020, 12, 16442-16450.
6. Q. Z. Sun, H. C. Wang, L. Wang, X. P. Yue, L. R. Zhang, G. Z. Ren, D. H. Li, Y. J. Han, L. L. Xiao, G. Lu, H. D. Yu, W. Huang. Fully sustainable and high-performance fish gelatin-based triboelectric nanogenerator for wearable movement sensing and human-machine interaction. Nano Energy, in revision.

technical paper

Chitin is the second most abundant biopolymer, after cellulose. It is present in the shell of crustaceans, in the cuticle of insect and even in some fungi. Chitin can be converted into chitosan, a highly praised material in the biomedical sector for its antibacterial properties, which finds also important application as a fertilizer, water treatment flocculant and food additive. Yet today's technologies for chitosan production from biomass rely on the use of corrosive treatments, high energy input and large quantities of by product effluents. Herein we are presenting our group's effort to tackle this question. We showed that mechanochemistry and aging could be used effectively for the deacetylation of chitin.1 This process yielded high molecular weight chitosan with minimal use of energy and solvent. This method is versatile and applicable to a number of chitin sources, including crude crustacean and insect shells, yielding deacetylation up to 98% and remarkably high molecular weights. This process affords chitosan in a safer fashion and with less materials and energy usage compared to the classic hydrothermal one. We have also extended this method to the fabrication of chitosan nanocrystals from chitin nanocrystals.2 Chitin and chitosan nanocrystals featured enhanced properties are nanocatalysts supports.3,4 We have also developed hydrogels from chitosan and chitin nanocrystals, with exceptional gelling properties and demonstrated their applicability for slow drug release.

Upcycling biomass: from crustacean waste to functional materials

Biopolymers such as chitosan, cellulose and alginate from biomass have demonstrated huge potential in many important and rapidly growing applications, it is always challenging to create advanced biopolymer materials cost-effectively. Herein, we present our progress in preparing a series of biopolymer composite materials with unexpected properties using a facile “dry”, thermomechanical method. Chitosan/CMC composite films created in this way showed much better hydrolytic stability, compared to chitosan-only films. This is so despite inclusion of the CMC in the chitosan matrix even increasing the surface hydrophilicity. We propose that our processing method led to the polyelectrolyte complexation between chitosan and CMC generating physical crosslinking points in the materials. These crosslinks stabilised the films in water although hydration disrupted hydrogen bonding between polysaccharide chains leading to dramatically decreased tensile strength and increased elongation at break.
Besides, we found chitosan/silk peptide (SP) polyelectrolyte-complexed materials prepared in the same way had extraordinary mechanical properties. Moreover, we prepared chitosan/alginate composites using the same processing protocol and demonstrate that inclusion of graphene oxide could enhance polysaccharide plasticisation, leading to enhanced mechanical properties and surface hydrophobicity.
The method of materials hybridisation without chemical reactions demonstrated in this work could provide an insight into the development of cost-effective biopolymer materials with competitive properties as plastic replacements in certain applications, where biodegradability, biosafety, and biocompatibility are indeed required (e.g. functional food packaging and antimicrobial wound healing).

Thermomechanically Processed, Polyelectrolyte-Complexed Polysaccharide Composites with Enhanced Hydrolytic Stability and Mechanical Properties

Plastics have become indispensable in the modern society. However, plastics pollution has also become a global environmental crisis that is projected to grow. The most common approaches to manage plastics pollution include mechanical recycling and pyrolytic waste-to-energy processes, but these methods inevitably lead to the increase in greenhouse gas emissions. In this presentation, I will summarize my team’s early contributions to using exclusively Earth-abundant elements and renewable energy to upcycle plastics. In particular, I plan to focus on our efforts at applying molecular vanadium complexes for selective, ambient condition, photoredox C-C cleavage reactions.1 We conducted detailed kinetic measurements to identify the fastest catalyst and the critical functional groups required in the substrates.2 The vanadium photocatalysts were then utilized for the C-C bond cleavage and oxygenation of over 30 substrates, including unactivated, commercially sourced alcohols and even non-biodegradable plastics.3-6

Figure 1. Photocatalytic upcycling of non-biodegradable polyethylene to formic acid, a liquid organic hydrogen carrier as a fuel.

References
1. Gazi, S.; Ng, W. K. H.; Ganguly, R.; Moeljadi, A. M. P.; Hirao, H.; Soo, H. S. Chem. Sci. 2015, 6, 7130-7142.
2. Gazi, S.; Dokić, M.; Moeljadi, A. M. P.; Ganguly, R.; Hirao, H.; Soo, H. S. ACS Catal. 2017, 7, 4682-4691.
3. Gazi, S.; Dokić, M.; Chin, K. F.; Ng, P. R.; Soo, H. S. Adv. Sci. 2019, 6, 1902020.
4. Dokić, M.; Chin, K. F.; Soo, H. S. Trends Chem. 2020, 2, 485-488.
5. Zhao, X.; Boruah, B.; Chin, K. F.; Dokić, M.; Modak, J. M.; Soo, H. S. Adv. Mater. 2021, in press.
6. Estahbanati, M. R. K; Kong, X. Y.; Eslami, A.; Soo, H. S. ChemSusChem, 2021, in press.

Photocatalytic Upcycling to Sustainably Reuse Plastics

High dielectric constant and low dielectric loss are desirable electrical properties for next generation polymer films for capacitive energy storage. Unfortunately, the dielectric constant of polymers is often limited to 2-5, much lower than that of inorganic dielectrics, because of the nature of hydrocarbon covalent bonds for electronic and atomic polarizations. It is essential to understand the fundamental physics of different types of polarization and the associated loss mechanisms in polymers. Among various approaches for high dielectric constant and low loss polymers, the multilayer film technology is of particular interest because a multilayer film is a unique one-dimensional system with tailored material choices, layer thicknesses, and interfaces. By minimizing the disadvantageous polarizations and enhancing the advantageous polarizations, multilayer films hold promise as advanced dielectrics for future polymer film capacitors.

High Energy Density and High Temperature Multilayer Polymer Films for Capacitive Energy Storage

The continuing growth of membrane technologies for water, solvent and gas separations, as well as other applications, has advanced significantly in the past few decades. However, the short durability of polymeric membranes, which wear out due to continuous fouling cycles and chemical cleaning, is increasingly becoming a waste disposal issue. The purpose of this presentation is to provide an overview of the environmental, energy and economic challenges and possible advantages of implementing sustainable processes in membrane manufacturing, evaluating the sustainability of membrane life-cycle and defining some end-of-life approaches such as reuse, repurposing and recycling. A bird’s eye review of the existing membrane challenges, state-of-art and potential sustainable solutions will be discussed in this presentation with examples from the literature.

Perspectives of sustainable development, life cycle and end of life in polymeric membranes

Membrane separations consume less than 90% of the energy required in incumbent industrial separation processes (absorption, distllation etc), and is widely considered as a "green" alternative for industrial separations. However, the manufacturing process of polymer membranes negates the "green" benefits of low energy. This is due to the mandatory use of oil-derived plastics and hazardous solvents e.g. NMP and n-hexane. At the Scale-Up Lab at The University of Edinburgh, we have deployed Green Chemistry concepts in tandem with additive manufacturing to imbue sustainability into polymer membrane fabrication. In this presentation, I will share with you key aspects of our work, including recycling plastic waste into high performance additives for mixed matrix membranes and replacing oil-derived plastics and overcoming the use of hazardous solvents in thin-film composite membrane fabrication.

Replacing plastics and hazardous solvents in polymer membrane fabrication

Repurposing of FRP Composites Using Next-Generation Technology


The needed massive deployment of lithium ion batteries (LIBs), in particular to satisfy the demand from the Electric Vehicle sector, encourage battery manufacturers to multiply the number of giga-factories to reduce the cost of production. Such a production consists of a complex process involving multiple steps, such as the slurry preparation, its coating, drying, calendering, electrolyte filling and formation. The choice of the manufacturing parameters along the process strongly impact the overall LIB cell performance. However, the optimization of the manufacturing parameters to obtain the desired characteristics of LIB cells is currently based on a forward "trial and error" approach. This approach is inefficient in terms of time and cost due to the infinite number of possibilities for adjusting the manufacturing parameters. The integration of Industry 4.0 concepts into giga-factories such as Artificial Intelligence (AI) and multiscale modeling is essential to accelerate the manufacturing process optimization and significantly raise the work efficiency of scientists, engineers and production line operators. Here I present our efforts in developing a digital twin of battery manufacturing [1], supported on a combination of physical and AI/machine learning models trained with data arising from in house high throughput characterizations. This digital twin allows simulating the different steps along the manufacturing process, predicting the resulting electrode properties and evaluating the associated electrochemical performance upon battery cell cycling. The predictive capabilities of this digital twin are illustrated with results for different electrode formulations, paving the way towards manufacturing digital optimization. Finally, data standardization challenges to ease the wide use of these tools in the battery field will be briefly discussed.

[1] www.erc-artistic.eu


Digitalization of Battery Manufacturing through Artificial Intelligence and Multiscale Modeling

Advanced two-dimensional (2D) materials have attracted significant interest due to their extraordinary physical and chemical properties over the past decade. Understanding and controlling the growth of novel 2D crystal materials for energy strorage application is central for the performance of the batteries. One of the greatest challenges besetting the development of battery technologies is fast charging, especially within flexible or compact designs. We discuss how the design of low dimensional nanostructure can correlate with the ion transportation efficiency, the activity of electrochemical reaction and energy storage based on chemical transformation. We have also studied the prospects of fast prototyping and scalability for 2D materials-based devices.

Design and Synthesis Low-dimensional Nanomaterials for Energy Storage Applications

Mixed Sn-Pb perovskites have shown their potentials in photovoltaics as a promising alternative to traditional silicon and other inorganic compounds. To achieve efficient devices, high-quality Sn-Pb perovskite thick films with well-packed, smooth, pinhole/void-free features are highly desirable for boosting spectral absorption. Herein, we propose an approach of double-side crystallization tuning through low-temperature space-restricted annealing in MA-free Sn-Pb perovskite films with over 1 μm thickness. Through simultaneously retarding the crystallization in the top of precursor films and promoting the crystal growth of the bottom of precursor films, we achieve high-quality and block-like thick Sn-Pb perovskite films with improved crystallinity and reduced trap density [1]. The high-quality Sn-Pb perovskite can also be fabricated on metal/ silicon substrates for direct integration with CMOS electronics for efficient photodiode imaging arrays [2]. Meanwhile, we develop the approach of in-situ tin(II) inorganic complex anti-solvent process to uniquely form the quasi core-shell structure of Pb-Sn perovskite-tin(II) complex as well as heterojunction perovskite structure. The Pb-Sn perovskite solar cells (SCs) achieves a high power conversion efficiency upto 19.03% with a fill factor over 0.8. Remarkably, the device fail time under continuous light illumination is extended by over 18.5 folds reaching 560 h [3]. To realize the integration of Sn-Pb perovskite for tandem cell applications, we also develop a new thermionic emission-based interconnecting layer (ICL) structure with the enhanced solvent-resistance feature. Fundamentally, thermionic emission plays a critical role in the electron transport process in the ICL, which is confirmed through both experimental and theoretical studies [4]. The works not only demonstrate the solid potential of Sn-Pb perovskite in SCs and photodetectors but also promoting all perovskite tandem SCs for low-cost photovoltaics.

[1] Adv. Funct. Mat. DOI:10.1002/adfm.202010532. [2] H.L. Zhu, W.C.H. Choy, et al, ACS Nano, 13, 11800, 2019. [3] C. Li, W.C.H. Choy, et al, Adv. Energy Mater., 10, 1903013, 2020. [4] C. Li, W.C.H. Choy, et al, Adv. Energy Mater., 8, 1801954, 2018.
