A microfluidic low pass filter LPF is a passive flow regulator fabricated by introducing the compliant element into the structure design , therefore controlling the flows with reduced needs from external facilities. Previous studies have reported such devices fabricated by soft lithography , However, soft lithography typically requires expertise, intensive laboring, and days of preparations which hindered the potential of a wider application and further commercialization. As the microfluidic market developed on a rapid basis recently the 3 D printing which emerged as a promising alternative to soft lithography due to its advantages such as rapid prototyping and computer-aided design process has received increasing attention in recent years . Besides, additive manufacturing also enables the modular paradigm where the individual elements could be harnessed in a plug n play way . In this work, we present a 3D printed design of microfluidic LPF, in which a modular assembly way is adopted . The characterization of the device is conducted and analyzed.
We demonstrate that this 3D printed LPF could work together with a PZT micropump to form a portable miniaturized mi microfluidic pumping system with stabilized flow output , which could be used in various applications in the future.

MATERIALS FOR HUMANITY (MH 21)

3D printed microfluidic low pass filter in modular paradigm
