Natural ceramic composites present complex microstructures that lead to tortuous crack path and confer them high toughness. Current microreinforced composites do not yet reach the level of complexity found in natural microstructures. To achieve this, we developed an automated set up for controlling 2D microplatelet orientation using magnetic fields. The setup has 4 degrees of freedom and allows fine control of platelet angles in 3D as well as position. With our setup, we can thus build microstructured porous ceramic materials (alumina) with local orientation of microplatelets, at a concentration of about 40 vol%. Other work in our group has shown that the same setup can be used to process microstructured ceramics up to 95 vol%.
Among the infinite possible microstructures, a nacre-like helicoidal arrangement was selected due to its ability to tilt and twist the crack path. Indeed, we used an analytical model based on the laminate theory to compare energy dissipation due to mixed modes of failure. Nacre-like helicoidal arrangement was predicted to exhibit the highest energy dissipation. Then, we fabricated the hybrid microstructured porous specimen fabricated and infiltrated them with a silicone matrix. Using compression tests, our hybrid dissipated 1.6 times more energy as compared to nacre-like samples of same composition. The fabrication strategy proposed here could thus be a simple route to increase the toughness of microplatelet reinforced composites.



MATERIALS FOR HUMANITY (MH 21)

Energy dissipation in composites with hybrid nacre-like helicoidal microstructures
