In this paper we report a series of breakthroughs that led to replication of gratings with a slant angle up to 60° and an aspect ratio of 10:1 in a material with refractive index of 1.90 (RI). A study of the replication process and materials optimization will be presented.

EIPBN 2021

Nanoimprint process to mass manufacture highly-angled high-RI gratings for augmented reality combiners

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
