High aspect ratio nanostructuring requires high precision pattern transfer with highly directional etching. In this work, we demonstrate the fabrication of structures with unprecedented ultra-high aspect ratios up to 10’000:1 in the nanoscale regime (down to 10 nm) by metal assisted chemical etching (MacEtch) of silicon in gas phase.
