We present the fabrication of ion sliced lithium niobate on oxidized silicon for integrated optics. Using structural modeling to optimize wafer thicknesses and a bonding apparatus to match wafer bows, an 817 nm thick lithium niobate film on oxidized silicon is achieved over a centimeter scale area.

EIPBN 2021

Stress reduction and wafer bow accommodation for the fabrication of thin film lithium niobate on oxidized silicon

direct bonding

ion-slicing

lithium niobate on insulator
