Width/depth and shape of volume of resist modified by ion beam as function of ion energy, exposure time and ion mass (He, Ne, Ar, Ga, Kr, Xe и Rn) is investigated by Monte-Carlo simulation. Sub-10nm resolution is found and confirmed. Analytical interpolating expressions for arbitrary ion mass, energy are submitted

EIPBN 2021

 Ion beam lithography: resist modification volume determination and sub-10nm resolution prediction via simulation

modelling

resist

ion lithography

The International Conference on Electron, Ion and Photon Beam Technology and Nanofabrication (EIPBN), affectionately known as "3-Beams," is the premier gathering of scientists and engineers who are dedicated to electron, ion and photon lithography, imaging, and analysis; atomically precise fabrication; nanofabrication process technologies and related emerging technologies; and their applications in a broad spectrum of fields. In its 64th meeting, researchers from academia, government laboratories, and industry from around the world meet to present and discuss recent and future trends in these technologies.
