The field of Quantum Microscopy (QM) promises highly efficient imaging for low absorption samples and microscopy at the single photon level. The recently developed Skipper-CCD detector technology is able to measure the charge in each pixel, repeatedly, in a non-destructive way. As a result, the readout noise can be reduced as much as desired [Tiffenberg et al, 2017]. It allows the precise counting of the number of electrons in each pixel ranging from empty pixel to more than 1900 electrons [Rodrigues et al. 2021]. In addition, they account for very high quantum efficiency (above 90% in the visible range), extremely low dark current (less than 1 electron per pixel per day), and high resolution (pixel size of 15 microns by 15 microns). The use of Skipper-CCD detectors opens the possibilities for multiple applications within this field. In particular, they are expected to provide comparable resolution and Noise Reduction Factor to state-of-the-art setups for QM, with a dramatically/drastically reduced photon count per pixel. The same advantage can be expressed as an order of magnitude increase in resolution for the same number of photons per pixel. This presents a valuable impact of QM applications in biology and chemistry, when avoiding damage of the sample is required [Taylor et al, 2012]. The status and plans for the implementation of Skipper-CCD in this field will be presented.

[Tiffenberg et al.] Single-Electron and Single-Photon Sensitivity with a Silicon Skipper CCD. Phys. Rev. Lett.,119,13,131802,2017,10.1103/PhysRevLett.119.131802
[Rodrigues et al.] Absolute measurement of the Fano factor using a Skipper-CCD. arXiv:2004.11499v3
[Taylor et al.] Biological measurement beyond the quantum limit. Nature Photon 7, 229–233 (2013). https://doi.org/10.1038/nphoton.2012.346
