The task of classifying objects at range in low resolution imagery is challenging due to a lack of clarity of the object and spatial information surrounding the object. Deep learning methods, while state-of-the-art when using high-volume, high-resolution data, often fail in this case. Additionally, it has been shown that these deep learning methods are highly susceptible to variations to the input data (e.g. illumination) and therefore can fail to generalize to new data.

In this presentation, we use the tracks of objects derived from video data to study the dynamics of the objects motion to distinguish between targets and confusers. Using a topological approach of embedding the motion tracks using a time-delay embedding, and computing persistent homology, we can identify targets and confusers with high accuracy. For comparison, we utilize deep learning approaches on images of the objects as well as the motion track data. We find the topological approaches are better able to differentiate the different types of objects at a variety of track lengths. In particular we see the most significant performance gains for the shortest track lengths. Moreover, we show that the topological approaches presented are better able to generalize to new data from tracks collected separately, and under different conditions, from those used to train the model. These results build on work showcased at the 2020 NAML and will also describe our first foray into applying these techniques to maritime activity classification from AIS data.

NAML 2021

I Spy in the Sea and Sky: Classification of Maritime and Aerial Targets
from Tracking Data

time delay embedding

topological data analysis

object tracking
