This Navy ManTech project, funded under ONR contract N00014-15-D-5003, focuses on the development of a head-mounted display (HMD) and high-dynamic-range (HDR) camera system to improve visualization for manual welding. We selected and integrated HDR cameras with a variety of head-mounted displays and used real-time image processing to produce a variety of working prototypes. In coordination with a subcontractor, we preformed evaluations in Pascagoula, MS.

Guided by the results of shipyard testing and additional optical evaluation, we selected and evaluated a number of candidate cameras and HMDs based on dynamic range, resolution, frame rate, latency, and suitability for wearing over an extended time period. The final system emphasizes visibility of the weld pool while also providing situational context to the welder.

TEAR 3M 2021

Augmented Visualization for Manual Welding

smart glasses

high dynamic range

welding camera
