Italy

Breathing rate together with heart rate, blood pressure,
and body temperature, are considered as essential and vital
signs of human body. In this demo, we present a novel system to
estimate the respiratory rate using a low-cost, non-intrusive, and
passive infrared thermopile sensor array. The thermopile sensor
array can detect the thermal infrared energy and generate a
low-resolution video from subjects within its viewing range. We
collected low resolution 8 8-pixel thermal video clips from 40
subjects at resting position from a distance of one-meter between
the thermopile sensor array and the subjects. We processed
the image frames using Haar-like filters and generated a one-dimensional
feature signal from each video. The signal exhibits
an almost periodic behavior following the respiratory movements.
A peak detection algorithm is used to detect each breath. The
proposed method is computationally efficient because it is based
on multiplierless Haar-type feature extraction and peak detection.
We achieved a high positive correlation rate of 97.77% between
the actual respiratory rate that was measured by monitoring
the chest movements during inhalation and exhalation and the
estimated rate in our dataset. We will demonstrate this IR array
based respiration rate detection system during the demo session.

ICPR 2020

Respiratory rate estimation using a low-resolution infrared sensor array

thermal images

haar-like filters

respiratory rate

thermopile sensor array

demo
