Magnetic resonance imaging (MRI) is widely used as a non-invasive diagnostic technique to visualize the internal structure of biological systems. Quantitative analysis of magnetic resonance signal lifetimes, i.e., relaxation times, can reveal molecular scale information and has significance in the study of brain, spinal cord, articular cartilage, and cancer discrimination. Determination of MR relaxation spectra (relaxometry) is an inherently ill-posed problem. Conventional methods to extract MR relaxation spectra are computationally intensive, requiring high quality data and generally lacking the spectrum peak width information. A novel computationally efficient signal analysis method, based on neural networks (NN), has been developed to provide accurate real-time quantitative MR relaxation spectrum analysis.
Deep learning with NN is a technique for solving complex nonlinear problems. NN have been optimized to determine 1D and 2D MR relaxation spectra. Simulated signals with Rician noise were employed for training the neural networks. The network performance was evaluated with simulated and experimental data, and compared with the traditional inverse Laplace transform (ILT) method. NN outperformed ILT. The 1D spectrum peak widths, generally considered not reliable with the traditional approach, could be determined accurately by the NN, noise permitting.
The proposed exponential analysis method is not restricted to magnetic resonance. It is readily applicable in other areas with exponential analysis, such as fluorescence decay and radioactive decay. The method could be extended to higher dimensional spectra and adopted to solve other ill-posed problems.

Magnetic Resonance Relaxometry with Neural Networks

Magnetic resonance imaging (MRI) is widely used as a non-invasive diagnostic technique to visualize the internal structure of biological systems. MRI has limited spatial resolution and the microscopic behaviour within an image voxel cannot be visualized with qualitative images. Quantitative analysis of molecular diffusion provides insights into the microscopic structure beyond the MRI image resolution. It is challenging to analytically derive the MR diffusion signals for complex microscopic environments, particularly with susceptibility effects. In this work, an easy to use open-source Monte Carlo algorithm has been developed to simulate MR diffusion measurements under arbitrary conditions.
The self diffusion of water molecules can be described by Brownian motion. The Monte Carlo method was applied to simulate the Brownian motion in a user-defined microscopic environment. The fast simulation can be performed on any MRI experiments with user-defined magnetic field distribution. The method has been applied to predict nanoparticle configuration. Magnetic nanoparticles, serving as biosensors, distort the local magnetic field leading to changes in the MR diffusion signals. The simulation agreed with the experimental results. The nanoparticle concentration in water can be determined with MR diffusion measurements.
We have developed an efficient, easy to use algorithm for rapid diffusion simulation in different microscopic environments with arbitrary magnetic fields. This simulation will be employed to optimize the nanoparticle biosensor systems for a wide range of targets, including cancer cells and COVID virus.

Monte Carlo Simulation for Magnetic Resonance Diffusion Measurements

M4-2 MR and PET Imaging - Part 2 (DPMB/COMP) / Imagerie RM et TEP - Partie 2 (DPMB/OCPM)

technical paper

**WELCOME TO THE 2021 CAP VIRTUAL CONGRESS UNDERLINE PLATFORM**

The CAP staff and our organizing and program committees are pleased to welcome you to our 2021 Congress filled with plenary talks, technical sessions/talks, student presentations and competition sessions, workshops, and several symposia offered by the CAP divisions and its partners.

You will also have opportunities to network with other delegates through the Gathertown platform accessed by selecting the lounge or posters button on the left.

Registered delegates should use the schedule button to call up the details of the session/event they wish to attend.  Each sessions includes a link to access the online platform where the event is taking place, either within Underline or through other Congress-related Zoom meetings.

Invited speaker talks are identified with an (I), and student competitors include a (G*) or (U*) to identify graduate or undergraduate presenters.

Please take the time to check out the information about our sponsors and exhibitors, request further information, or leave a note of thanks for their support.

General information about the Congress can be found on the CAP website Congress pages at https://www.cap.ca/congress/2021.

Looking for a specific talk?   A full searchable list is available on our Indico Congress site at https://indico.cern.ch/event/985448/contributions/

We look forward to sharing this exciting week with you!


Tristhal Parasram

2

SHORT BIO

Presentations

Magnetic Resonance Relaxometry with Neural Networks

Monte Carlo Simulation for Magnetic Resonance Diffusion Measurements
