La(Fe, Si)13 is a promising candidate for magnetocaloric based technology such as magnetic refrigeration or energy harvesting [1-3]. This alloy family consists of a low content of rare earth (7.1 at. %) and high content of iron, resulting in a cheap and non-toxic compound. La(Fe, Si)13 based alloys exhibit a large magnetocaloric effect (MCE) at the transition between ferromagnetic and paramagnetic states, which occurs at Curie temperatures (Tc) ranging between 200-259K [4]. The magnetic properties (Tc, magnetization, MCE), the crystal structure (cubic or tetragonal) and the type of transition can be tuned by adjusting the Si content. Furthermore, the Curie temperature can be increased to above room temperature by doping and hydrogenation [5]. Recently our group reported for the first time the possibility to fabricate thick films of La(Fe, Si)13 [6]. Here we present a study on compositionally graded films of La-Fe-Si. The films were fabricated by triode co-sputtering of three targets (La-Fe, Fe, Si-Fe) onto thermally oxidised stationary Si substrates (100 mm in diameter). The composition of the as-deposited films was mapped by EDX, as shown in Fig. 1. The films were annealed ex-situ in a rapid thermal annealing furnace at 900°C. For each film, we selected samples from specific regions for characterization using optical and scanning electron microscopy, VSM-SQUID magnetometry and X-ray spectroscopy. Fig. 2 displays M(T) measurements on four La-Fe-Si samples of 5 μm thickness, taken from the regions specified in Fig. 1. The presentation will report results from films of nominal thickness ranging between 150nm – 5μm. The presentation will give details about how the structural and magnetic properties vary as a function of film composition, thickness and annealing conditions. Prospects for further developments and possible applications will also be discussed. Acknowledgement: This research has received funding from the French National Research Agency under the HiPerTherMag project (ANR-18-CE05-0019).

![](https://assets.underline.io/uploads/markdown_image/1/image/e47b4016b72ccd38f00fea3375cd00d9.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/a06f84bea07fbcfb4eb5845d9b87a6ea.jpg)

Compositionally graded La-Fe-Si films

Compositionally graded La-Fe-Si films

Internet of Things devices prompt a rising demand for autonomous and compact power supply generators to sustain low-power wireless sensor nodes. Due to the ubiquity of waste heat in buildings and urban environments, low-grade heat sources are very attractive for applications. Thermomagnetic generators (TMG) can be small and autonomous. Ahmim’s TMG [1] produces 4.2 μW (0.24 mW/cm3 over a 35°C temperature difference. While this device exploits direct thermal contact with both reservoirs, a key element of a thermal device [2], the output power is penalized by a sub-Hertz working frequency. Khol’s TMG [3] produces 118 mW/cm3 at 84 Hz but over a larger temperature difference of 138°C. Their use of 5 μm thick Heusler Alloy films, compared to a 250 μm thick plate of LaFeSi by Ahmim, is an important factor to explain the different in the working frequency. We aim to explore the possibility to use thin films in Ahmim’s TMG while keeping its low temperature difference capability. Ahmim’s TMG has specific characteristics. Firstly, it needs to have a freestanding magnetocaloric film of several micrometers. Our recent work on Gd film deposition has shown a 17 μm film with significant magnetocaloric effect [4]. Secondly, it needs to have a magnetic field source that gives a maximum field variation but also confines the magnetic field in order to reduce the film displacement. By combining Gd films and high performance NdFeB micro-magnets [5], [6] with our design experience on macro devices (Fig.1), we will discuss the key steps of the design, e.g., the spring characteristics to achieve self-oscillating micro-devices. Several parameters need to be optimized, such as the micro-magnet pattern, the air gap and Gd film thickness. 3D numerical simulations of the magnetic force as a function of the material position and temperature (Fig. 2), which are being used to optimize the system design, will be discussed in detail. With our proposed design, if we assume a 50 Hz working frequency, there is 5mW of mechanical energy available.

![](https://assets.underline.io/uploads/markdown_image/1/image/6c8def3c8eadc39bbbf231f211465813.jpg)

![](https://assets.underline.io/uploads/markdown_image/1/image/d44ec31fe73d8d8565d56c704b72f012.jpg)

Key steps in designing a micro thermomagnetic generator

Key steps in designing a micro thermomagnetic generator

Gadolinium is the simplest material with a strong magnetocaloric effect close to room temperature (Tc = 293 K) and no thermal hysteresis [1], making it an ideal test-bench material for magnetic refrigeration and energy harvesting prototypes [2,3]. Gd ribbons of thickness 36-215 μm were prepared by cold-rolling [4] while films of thickness 20-150 μm were deposited by evaporation onto dimpled Hastelloy substrates [5]. More recently, films of thickness in the µm range were made by magnetron sputtering [6,7]. Here we present a study of Gd films of thickness in the range 3.5 - 40 μm, deposited by triode sputtering onto Si substrates at RT or 400°C, with Ta buffer and capping layers. As has been reported in magnetron sputtered films [7], our triode sputtered films can be removed from the substrate to produce free-standing films, and peel-off is easiest for films deposited at elevated temperature. Films were characterized structurally (optical and Scanning Electron Microscopy, XRD), magnetically (VSM-SQUID, extraction magnetometer) and mechanically (interferometer, nanoindenter). An SEM image of the fractured cross section of a 20 µm thick film deposited at 400°C is shown in Fig. 1, together with θ-2θ XRD patterns from the upper and lower surfaces of the film. It can be seen that the film texture changes from (00l) at the lower surface to (103) at the upper surface. A spin-reorientation transition is clearly seen in the M(T) curve of a 3.5 µm thick film, while it becomes smeared in thicker films (Fig. 2), owing to the evolution in crystallographic texture. In this presentation we will report on the influence of film thickness and deposition temperature on the structural, magnetic and mechanical properties of Gd films, which are being developed for integration into micro-scaled thermal energy harvesting devices [3]. Acknowledgement: This research has received funding from the French National Research Agency under the HiPerTherMag project (ANR-18-CE05-0019).

![](https://assets.underline.io/uploads/markdown_image/1/image/dd535808ff17c217e3a7ead00118fb60.jpg)


Fig. 1 Left: SEM image of a 20 µm thick Gd film deposited at 400 °C. Right: θ-2θ XRD spectra from the upper and lower surfaces of the film, following peel-off from the substrate.


![](https://assets.underline.io/uploads/markdown_image/1/image/f29d014564fd1b808054343a926d5a44.jpg)

Fig. 2 Magnetization vs temperature, measured under 50 mT, of Gd films deposited at 400°C.

Structural, magnetic and mechanical properties of Gd films

Permanent magnets are a key component of a wide range of everyday devices, including motors, actuators, transducers and sensors. Depending on the application needs, magnets are based on high performance rare-earth transition metal phases or on more moderate performance hard ferrite phases, and they may be sintered or polymer bonded. While the remanence of bonded magnets is necessarily limited by dilution of the magnetic material in a non-magnetic matrix, they are cheaper in both material and fabrication costs. What is more, the mechanical properties of the magnets can be tuned according to the choice of matrix. Traditional fabrication routes for polymer bonded magnets include calendering, injection moulding, extrusion, and compression bonding [1] and there has been much recent activity concerning 3D printing of polymer bonded magnets [2,3,4]. Down-sizing magnets opens new opportunities for their use in micro-scaled devices with applications in fields as diverse as telecommunications, energy management and bio-medicine. Sputtering combined with micro-patterning has been used to make fully dense magnets which are a micro-scale equivalent to sintered magnets while various techniques including casting and screen printing combined with photo-lithography have been used to make polymer bonded micro-magnets [5]. Sputtered films may be isotropic or textured, depending on the deposition temperature, whereas micro-scaled polymer bonded magnets reported to date are isotropic. Here we present a process developed to fabricate arrays of anisotropic, flexible bonded micro-magnets. The study focuses on micro-magnets prepared using commercial single crystalline hard ferrite (Br: 195 mT, Hc: 123 kA/m) or Sm-Fe-N (Br: 1.31 T, Hc: 889 kA/m) powders mixed with polydimethylsiloxane (PDMS). This binder was chosen so as to have flexible micro-magnets that can be used to study the influence of mechanical forces on cell development [6]. The innovative aspect of this process, schematized in Fig. 1, consists in the possibility to transfer a specific pattern from a silicon mould, made by deep reactive ion etching (DRIE), to a magnetically aligned powder-polymer composite. The composite is maintained within the mould during the alignment step by coverage with a glass slide. A first soft curing step is performed with the cover-slide in place, then a final curing is performed to attach the micro-magnets to a PDMS base. The procedure has been used to fabricate arrays of micro-magnets of thickness ranging from 50 µm to 300 µm and width in the range from 20 µm to 4000 µm. As a magnetic field source, bulk magnets, a superconductive coil and pulsed magnetic field systems were tested. The degree of alignment was assessed by measuring the hysteresis loops of fully cured micro-magnet arrays with the measuring field applied parallel or perpendicular to the direction of the alignment field. Note that these measurements were made prior to removal of the arrays from the Si mould, to prevent distortion of the flexible micro-magnets under the torque induced by the measuring field. As an example, easy and hard axes hysteresis loops made on an array of SmFeN-bonded square micro-pillars with in-plane dimensions of 200x200 µm2 and a height of 300 µm, aligned in a magnetic field of 800 mT, are compared in Fig. 2 a. As can be expected, higher intensity fields were needed to align the SmFeN particles compared to the ferrite particles. The stray fields produced by aligned and non-aligned micro-magnet arrays were measured using an in-house developed Scanning Hall Probe Microscope [7]. In Fig. 2 b we present the z-component of the stray field produced at a height of 50 µm above the SmFeN micro-magnet array featured in Fig. 2 a. In this presentation, we will give details of structural and magnetic characterisation as well as simulations of arrays of ferrite and SmFeN bonded micro-magnets. We will also report on the actuation of these micro-magnets under the influence of a 3D magnetic field. Finally, we will present prospects for the further development and use of such micro-magnet arrays.

**References:**

[1] J. Ormerod and S. Constantinides, Journal of Applied Physics, Vol. 81, p.4816 (1997) [2] C. Huber, C. Abert and F. Bruckner, Appl. Phys. Lett. , Vol. 109, p.162401 (2016) [3] L. Li, A. Tirado and I. C. Nlebedim, Scientific Reports, Vol. 6, p.36212 (2016) [4] K. Sonnleitner, C. Huber and I. Teliban, Appl. Phys. Lett., Vol. 116, p.092403 (2020) [5] N.M. Dempsey, "Nanoscale Magnetic Materials and Applications", J.P. Liu et al.(eds), p.661, (Springer 2009) [6] N.M. Dempsey, " Handbook of Magnetic Materials", J.M.D. Coey et al. (eds), Springer, (in-press) [7] G. Shaw, R.B.G. Kramer and N. M. Dempsey, Rev Sci Inst, Vol.87, p.113702 (2016)

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/3a78eeb2c7e66ef3542f55dd6887a55f.jpg)
Fig. 1 Schematic of the process developed for the fabrication of arrays of flexible, anisotropic bonded micro-magnets.

![](https://assets.underline.io/uploads/markdown_image/1/image/a01987af8c35d1a195ab777fd1bb4d16.jpg)
Fig. 2 (a) Hysteresis loops of an array of SmFeN (30 vol %) - PDMS (70 vol %) bonded micro- magnet pillars with in-plane dimensions of 200x200 µm2 and a height of 300 µm. (b) Z-component of the stray magnetic field produced by this array, measured using a micro-Hall probe scanned at a height of 50 µm above the magnet array.

 Fabrication and characterisation of polymer-bonded flexible anisotropic micro-magnet arrays
