I. INTRODUCTION With the increasing risk of global rare earth supply and the growing environmental cost of recycling Nd2Fe14B waste by conventional hydrometallurgical technology, development of green and efficient recycling technology has become particularly important [1]. Recently, the reduction diffusion (RD) technology has been developed as an eco-friendly method for recycling Nd2Fe14B sludge waste [2]. At present, researchers mainly use granular calcium or CaH2 as reducing agent, and the amount of reducing agent will affect the phase, morphology, and magnetic properties of recycled powders [3]. Owing to the differences in physical and chemical properties of different reducing agents, the phase, morphology, and magnetic properties of the powders are substantially different in the recovery process. However, the influence of different reducing agents to the recovery of Nd2Fe14B sludge waste by RD method is rarely reported. In this paper, we respectively used granular calcium and CaH2 as reducing agents to recycled Nd2Fe14B sludge waste by RD method. The effect of different reducing agents on the phase, microstructure, and magnetic properties of the recycled powder were investigated. II. EXPERIMENTAL The multi-wire cutting sludge waste was collected from Anhui Earth-Panda Advance Magnetic Material Co. Ltd. The sludge was purified and then mixed with appropriate amount of Ca or CaH2. The mixtures compacted and heated to 1073 K, 1123 K, 1173 K, and 1323 K under high purity argon atmosphere for 2 h. Finally, deionized water was used to wash the powder for removing CaO and then vacuum dried at room temperature to obtain the recycled powders. The phase and orientation were characterized by X-ray diffraction meter (XRD). Microscopic morphology was observed by scanning electron microscopy (SEM). The magnetic properties of the samples at room temperature were measured by a vibrating sample magnetometer (VSM) with a maximum magnetic field of 3T. III. RESULTS AND DISCUSSIONS The XRD patterns of the recycled powders at different reaction temperatures are shown in Fig. 1. The results show that single phase Nd2Fe14B powder can be obtained with granular calcium as the reducing agent at 1323 K. However, when CaH2 is used as the reducing agent, single phase Nd2Fe14B powder can be obtained at 1123 K. This indicates that the latter can carry out the RD reaction at lower reaction temperature. In addition, Fig.1(a) shows that the diffraction peak of Nd2O3 is detected at 1073 K, which indicates that the Ca has not completely reacted with Nd2O3, but the diffraction peak of Nd2O3 is not detected at 1073 K with CaH2 as reducing agents. This proves that CaH2 is more prone to reduction reactions since the melting point of CaH2 (948 K) is lower than that of Ca (1115 K), so the former can be liquefied at lower temperature and thus liquid-solid RD reactions can occur more easily. In addition, since the size of CaH2 powder is smaller than that of granular calcium, it can be better mixed with sludge waste, which is beneficial to promote the RD reaction. On the other hand, the magnetic properties of the recovered powder of the latter (M3T=141.55 emu/g) are higher than that of the former (M3T=137.00 emu/g). And the M3T is increased by 12.9% compared with the purified sludge raw material (M3T=125.38 emu/g). To explore the reason, we observed the morphology of the cross section and powder of the products, and the results are shown in Fig. 2. Since CaH2 releases hydrogen during the RD process, there are many pores in the cross section as shown in Fig.2(c), instead of the dense and smooth cross section shown in Fig. 2(a). From Fig.2(b), it can be seen that the powder has severe sintering and agglomeration, but the dispersion of the powder is better and the powder particle size is more uniform in Fig. 2(d). Owing to the better dispersibility, it is easier to remove CaO during the washing process, so the non-magnetic phase and oxygen content in the corresponding washed magnetic powder are lower, which is also the reason for the better magnetic performance. IV. CONCLUSIONS In summary, using CaH2 as a reducing agent can obtain a single-phase Nd2Fe14B powder at 1123 K by RD method, which is lower than the 1323 K with Ca as the reducing agent. Besides, the dispersion of the powder is better and the powder particle size is more uniform. The magnetic properties of the recovered powder of the former (M3T=141.55 emu/g) are higher than that of the latter (M3T=137.00 emu/g). And the M3T is increased by 12.9% compared with the purified sludge. ACKNOWLEDGEMENT This work was supported by the National key R & D project (2018YFC1903405, No. 2016YFB0700902), and by State Key Laboratory of Rare Earth Permanent Magnetic Materials Opening Foundation (No. SKLREPM17OF02).

**References:**

[1] O. Takeda, T.H. Okabe. Metall. Mater. Trans. E. 1 (2014) 160-173. [2] S.K. Haider, J.Y. Lee, D. Kim, Y.S. Kang. ACS Sustainable Chem. Eng. 8 (2020) 8156-8163. [3] C.Q. Chen, D. Kim, C. Choi. J. Magn. Magn. Mater. 355 (2014) 180-183.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/cfe0e3b8c51ae6e7f90d40fc0c30d0d5.jpg)
Fig. 1 XRD patterns of recycled powder obtained at different temperatures with Ca (a) or CaH2(b) as reducing agent, and recycled powder after washing (c) and the hysteresis loop of recycled powder (d)

![](https://assets.underline.io/uploads/markdown_image/1/image/173ce736e80abaa2509bfd3607afee06.jpg)
Fig.2. SEM micrograph of the cross section and recycled powder of the reaction products with Ca (a and b) or CaH2 (c and d) as reducing agent

 Influence of reducing agent to recovery of Nd2Fe14B sludge waste by Calcium reduction diffusion method
