I. INTRODUCTION Hybrid-magnetic-circuit variable flux memory machine (HMC-VFMM) [1] can combine the advantages of wide flux adjusting range in parallel type [2] and beneficial on-load demagnetization withstand capability in series type [3]. The rotor pole number plays an essential role in the electromagnetic performances of conventional PM machines [4]-[6]. In addition, the design process of HMC-VFMM needs to consider not only the basic performance metrics, such as the torque capability, but also flux regulation range and on-load magnetic stability of low coercive force (LCF) magnet. Thus, it is crucial to provide and generalize a utility design guideline for choosing proper pole number for VFMM. This paper attempts to analyze the electromagnetic performances of HMC-VFMMs with different rotor pole numbers. The influence rules of different rotor pole numbers on the performance metrics of the HMC-VFMMs are then provided, and a 4-pole machine prototype is manufactured and tested to experimentally validate the theoretical analyses. II. TOPOLOGIES AND WINDING LAYOUTS OF HMC-VFMM The investigated objectives of this paper refer to HMC-VFMMs with 36-slot/4-pole, 36-slot/6-pole and 48-slot/8-pole combinations, which are all characterized by integer slot structures. The double-layer and full-pitch windings are utilized in all machine models, as shown in Fig. 1. For the parallel branch, the “U”-shaped hybrid magnets are employed. For the series branch, the HCF PMs feature a spoke-type configuration. And only A-phase winding is shown here. III. ELECTROMAGNETIC PERFORMANCE AND COMPARISON Fig. 2 (a) shows the rated-load torque waveforms of HMC-VFMMs with different rotor pole numbers under the conditions of flux-enhanced and flux-weakened states, respectively. It can be seen that with the increase of rotor pole number, the average torque shows an increasing trend, while the torque ripple decreases. These results indicate that the increase of rotor pole number can improve the torque performance to a certain extent. The variations of LCF PM working point subject to an intermediate on-load operation in HMC-VFMM are illustrated in Fig. 2 (b). The excellent on-load demagnetization withstand ability can be observed in all machines. The variations of the back-EMF fundamental magnitudes with the remagnetizing and demagnetizing currents are plotted in Fig. 2 (c). It can be seen that the increase of rotor pole number enlarges the adjusting range of the fundamental back EMF. However, higher current magnitudes are required for full magnetization in the high rotor pole cases at the same time. The detailed characteristics analysis, comparison results and experimental verification will be presented in the full paper.

**References:**

[1] H. Yang, S. Lyu, H. Lin, Z. Zhu, H. Zheng and T. Wang, "A Novel Hybrid-Magnetic-Circuit Variable Flux Memory Machine," IEEE Trans. Ind. Electron., vol. 67, no. 7, pp. 5258-5268, July 2020 [2] K. Sakai, K. Yuki, Y. Hashiba, N. Takahashi, and K. Yasui, “Principle of the variable-magnetic-force memory motor,” in Proc. Int. Conf. Electr. Mach. Syst., Tokyo, Japan, 2009, pp. 1-6. [3] A. Athavale, K. Sasaki, B. S. Gagas, T. Kato, and R. D. Lorenz, "Variable flux permanent magnet synchronous machine (VF-PMSM) design methodologies to meet electric vehicle traction requirements with reduced losses", IEEE Trans. Ind. Appl., vol. 53, no. 5, pp. 4318-4326, Sep./Oct. 2017. [4] J. T. Chen and Z. Q. Zhu, "Winding Configurations and Optimal Stator and Rotor Pole Combination of Flux-Switching PM Brushless AC Machines," IEEE Trans. Energy Convers., vol. 25, no. 2, pp. 293-302, Jun. 2010. [5] M. Ibrahim, L. Masisi and P. Pillay, "Design of Variable Flux Permanent-Magnet Machine for Reduced Inverter Rating," IEEE Trans. Ind. Appl., vol. 51, no. 5, pp. 3666-3674, Sep./Oct. 2015.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/52ccf8fa246dc06e66bbb6bc29976068.jpg)
Fig. 1. Topologies and winding layouts (A-phase) of three HMC-VFMMs.

![](https://assets.underline.io/uploads/markdown_image/1/image/8cecce5efa57003da28f93e3cdd6c375.jpg)
Fig. 2. (a) Steady-state torque waveform @ rated load. (b) Working point variations of the LCF PM in the HMC-VFMMs subject to an intermediate on-load operation. (c) Back-EMF magnitudes versus the current pulses (1500r/min).

 Influence of Rotor Pole Number on Electromagnetic Performance of Hybrid-Magnetic-Circuit Variable Flux Memory Machine

I. INTRODUCTION Due to the absence of neither permanent magnets (PMs) nor windings on the rotor, stator wound-field synchronous (SWFS) machines [1]-[5] were presented for potential applications to domestic appliances and more-electric aircraft, and renewable energy, etc. SWFS machines have the advantages of the eliminations of brushes and slip rings, low cost, fault tolerance, simple as well as a robust double salient structure similar to switched reluctance machines (SRMs) [6], which are suitable for critical-safety applications. Besides, the demerits of high torque ripple, acoustic noise, and vibration in SRM are alleviated with the SWFS machines which can be fed by a standard three-phase full-bridge inverter. Nevertheless, the existence of additional DC windings makes SWFS machines suffer from restricted torque density and redundant DC power source. Thus, the variable flux reluctance machines (VFRMs) [5] [7] with integrated DC bias and AC current excitations were developed by using an open-winding winding configuration to offer DC excitations. However, the inherently unipolar coil flux linkage in VFRMs still results in a relatively low torque density. Therefore, this paper attempts to propose a novel wound field switched flux (WFSF) machine with a zero-sequence field current excitation. An open-winding circuit is employed to generate a zero-sequence current to offer DC excitation. Moreover, the SF working principle will be employed to improve the torque capability compared to the VFRM. In this paper, the machine topology, operating principle, and design considerations will be described, respectively. Then the major electromagnetic performance will be analyzed and compared with the conventional WFSF counterpart, which confirms the superiority of the proposed design. II. MACHINE TOPOLOGIES AND OPERATING PRINCIPLE Figs. 1 (a) and (b) show the WFSF machines with conventional separate and integrated DC and AC excitations. It demonstrates that the two machines are with identical stator/rotor doubly salient structure and single-layer overlapping winding layout. The main difference lies in the winding functions of the two sets of windings in the two WFSF machines. In the conventional WFSF machine [2]-[4], one set of winding serves as continuous DC excitation while another works as the armature winding. On the other hand, two sets of windings are both injected with integrated AC plus DC bias currents in the WFSF machine with zero-sequence field current excitation. As a result, more copper area is available for the armature windings in the proposed WFSF machine with integrated “AC+DC” current excitations. The control circuit is illustrated in Fig. 1(c), in which the open-winding-based dual three-phase inverter with a single voltage source is utilized [7], and the output terminals of two inverters are connected to both ends of the stator windings. This method is the utilization of the constant zero-sequence current acting as the field current, while two three-phase currents are controlled by two inverters. The operating principle of the proposed WFSF machine is shown in Fig. 1(d). For each group armature windings, such as A1 and B2, when A1 is injected with continuous DC current, and the sinusoidal flux linkage will be induced in B2, and vice versa. As a result, when an AC sinusoidal current with a DC bias is applied to both two coils A1 and B2, the effective electromagnetic energy conversion will be achieved similar to those conventional WFSF counterparts [2]-[4]. III. ELECTROMAGNETIC PERFORMANCE AND COMPARISON Fig. 2(a) shows the open-circuit coil and phase flux linkage waveforms, it can be the DC biases in two individual coils are canceled, and a bipolar and sinusoidal phase flux linkage can be obtained. Besides, the open-circuit phase back-EMF waveforms at 400 r/min are shown in Fig. 2(b). It can be observed that the back-EMF is symmetric and sinusoidal in the WSFC machine with zero-sequence field excitation, while asymmetric non-sinusoidal for the conventional case. This is mainly attributed to the fact that the dual three-phase winding arrangement in the proposed machine allows the even-order harmonic cancellation within one phase. Besides, the steady torque and torque versus current characteristics of the two machines are compared as shown in Figs. (c) and (d), respectively. It should be noted that the winding turns of the two machines are designed as the same for a fair comparison. As a result, it demonstrates the WSFC machine with zero-sequence field excitation exhibits 68% higher magnitudes of steady torque, together with 30.4% lower torque ripple than the conventional case. Meanwhile, it demonstrates that the average torques of the proposed machine exceed that of the conventional counterpart regardless of the armature current excitations. Thus, better electromagnetic performance can be obtained with the proposed design with zero sequence field excitation. The detailed characteristics analysis, comparison results, and experimental verification will be presented in the full paper.

**References:**

[1] Z. Q. Zhu, Y. J. Zhou, J. T. Chen and J. E. Green, “Investigation of nonoverlapping stator wound-field synchronous machines.” IEEE Trans. Energy Convers., vol. 30 no. 4, pp. 1420-1427, May. 2015. [2] H. Pollock, C. Pollock, R. T. Walter, and B. V. Gorti, “Low cost, high power density, flux switching machines, and drives for power tools,” in Conf. Rec. 38th IEEE IAS Annu. Meeting, Oct. 2003, vol. 3, pp. 1451–1457. [3] Y. Tang, J. J. H. Paulides, T. E. Motoasca, and E. A. Lomonova, “Flux switching machine with DC excitation,” IEEE Trans. Magn., vol. 48, no. 11, pp. 3583-3585, Nov. 2012. [4] B. Gaussens, E. Hoang, O. Barriere, J. Saint-Michel, and M. Gabsi, “Analytical approach for air-gap modeling of field-excited flux-switching machine: No-load operation,” IEEE Trans. Magn., vol. 48, no. 9, pp. 2505–2517, Sep. 2012. [5] X. Liu and Z. Q. Zhu, “Electromagnetic performance of novel variable flux reluctance machines with dc-field coil in stator,” IEEE Trans. Magn., vol. 49, no. 6, pp. 3020-3028, Jun. 2013. [6] K. Vijayakumar, R. Karthikeyan, S. Paramasivam, R. Arumugam, and K. N. Srinivas, “Switched reluctance motor modeling, design, simulation, and analysis: a comprehensive review,” IEEE Trans. Magn., vol. 44, no. 12, pp. 4605-4617, Dec. 2008. [7] Z. Q. Zhu, B. Lee, and X. Liu, “Integrated field and armature current control strategy for variable flux reluctance machine using open winding,” IEEE Trans. Ind. Appl., vol. 52, no. 2, pp. 1519-1529, Mar./Apr. 2016.

**Images:**

![](https://assets.underline.io/uploads/markdown_image/1/image/16bc6a2168fbe73c6a5b2b933b4fc140.jpg)
Fig. 1. Topologies of the WFSF machines (a) with zero-sequence field current excitation and (b) conventional separate AC and DC windings. (c) Control circuit. (d) Operating principle.

![](https://assets.underline.io/uploads/markdown_image/1/image/ac8f544001c98b644d34bbc569f7b5d0.jpg)
Fig. 2. Electromagnetic characteristics comparison. (a) Flux linkages in the proposed machine. (b) Back-EMFs. (c) Steady-state torque. (d). Torque versus current characteristics.

 A Novel Wound Field Switched Flux Machine with Zero-Sequence Field Current Excitation
