An important task in micromagnetics is performing a large ensemble of simulations of a structure with only one or a few changed parameters. An example is computing write error rates in magnetic random-access memories (MRAM), where simulations are needed for different stochastic thermal fields. Such computations, which are done by multiple runs on a single or multiple computing devices. have various numerical overheads related to preprocessing, matrix operations, and excessive data storage. We demonstrate a computational approach for performing a large batch of repetitive micromagnetic simulations on a Graphics Processing Unit (GPU) simultaneously. This batched approach has the following benefits: (i) it utilizes GPUs much more efficiently than the traditional approach of running multiple simulations, including much increased speed and reduced memory consumption, (ii) it hides various numerical overheads, such as preprocessing as well as matrix and time stepping operations, (iii) it makes obtaining results and post-processing much more efficient by allowing computing only required properties, e.g. ensemble averages or switching counts. We extended our FEM based micromagnetic framework FastMag to implement the batched approach in all code components, including pre-processing, matrix operations (Fig. 1a), time stepping with adaptivity to step, order, and decisions of a stopping evens per instance (Fig. 1b). Figure 2 shows major improvements of the computational time and memory consumption for switching simulations of an MRAM cell using three 100-instance batch scenarios on an Nvidia GTX1080 GPU: sequential launching of 100 instances, simulating a 100 x 100 array of sufficiently separated cells (to prevent the strong magnetostatic coupling), batched approach. This work was supported as part of the Quantum Materials for Energy Efficient Neuromorphic Computing, an EFRC funded by the U.S. DOE, Office of Science.

High-performance micromagnetics on GPUs for batched simulations

P3: Micromagnetic Modelling II

technical paper
