In this paper, we propose some layout guidelines to significantly mitigate the charging damage from well-side antennas in separated power domains. The circuit topologies that consist of aggressor-victim pairs. The guidelines are based on the test patterns that cover adequate combinations of different geometries of isolation wells, metals, and vias, as well as different well configurations. The method has been verified in 0.13µm BCD (Bipolar-CMOS-DMOS) process using NBL (N-type Buried Layer) as the isolation well.

Layout Guidelines against Charging Damage from the Well-Side Antenna in Separated Power Domains

In this paper, a new failure model that explains the plasma-induced damage (PID) involving two wells is described. Contrary to common explanation that the larger wells discharge and damage devices in smaller wells, we propose that the damage is caused by an imbalance of the “RC” associated with each “well system”.  The victim gate can reside in either the large or small well.  This RC imbalance model is supported by the results of various test patterns designed in a 0.13um BCD (Bipolar-CMOS-DMOS) process using NBL (N-type Buried Layer).  New design rules have been developed based on the test pattern results.

New RC-Imbalance Failure Mechanism of Well Charging Damage and The Implemented Rule
