In this presentation we discuss the design, implementation and measurements of Tb/s/channel optical communication circuits realized in III-V Lab InP DHBT process. Realizations using InGaAs- and GaAsSb-base devices will be presented and compared, from transistor to circuit performances.
The design flow is detailed with specific focus on key trade-offs to reach >3-4 Vpp output swings conjugated with >100 GHz analog bandwidth as well as circuits’ design for electro-optical systems with new transmission formats using innovative DSP algorithms allowing higher transmission rates and increased spectral efficiency, like m-ary pulse-amplitude modulation (m-PAM) or quadrature amplitude modulation (m-QAM) formats. We also present the design and measurements of digital multiplexing selector operation at record 212-GBd speed and its system implementation for intra data-center communications.


Recent advances in high-speed and large-swing integrated circuits implemented in InGaAs and GaAsSb InP DHBT for terabit-class optical communications

**Monday, September 22nd**

**Session Chairs:** Cristell Maneux *IMS Bordeaux* and Virginie Nodjiadjim *III-V Lab*

Today, the ever growing communication services such as remote work, e-learning, e-healthcare and intensification of social relations supported by massive data transmission, give a new impulse to further investigate various methods to increase transmission network capacities with Tb/s/channel objective. This workshop will give insights into different key aspects of the device-to-circuit value chain highlighting the need for devices combining very high symbol rate multi-level signal generation with large output swing to efficiently drive electro-optical (E/O) modulators.

A variety of novel (i) InP DHBT devices –both InGaAs and Sb types-, (ii) calibration and measurement approaches, (iii) physics-based device simulation coupled methods including compact model and (iv) state-of-the-art E/O modulator results are covered in this workshop.
The consistency of the whole value chain leads, for instance, to very-high-symbol-rate PAM (or QAM) modulation formats.

**This session has 10 lectures. If you don't see them all please click on the 'SEE ALL' button located in the top right corner of the page**
