**Please read the paper on the following link:**

https://ieeexplore.ieee.org/document/9203868

**Abstract:**

A 6.4 nW 1.7 % relative inaccuracy (R-IA) CMOS sub-thermal drain voltage-based temperature sensor is proposed. The proposed stabilized sub-thermal drain voltage current generator achieves a highly linear PTAT output without nonlinearity fitting or post-fabrication trimming, and increases the accuracy of the sensor. The combination of the current generator and a frequency-locked-loop relaxes the tradeoff between power and temperature stability of the current-to-frequency converter, and achieves supply-voltage-independent operation. Measured results of the prototype fabricated in a 65 nm CMOS process show that the proposed temperature sensor has a -1.0/+0.7 °C inaccuracy (= R-IA of 1.7 %) while achieving a resolution of 75 mK over a temperature range of -30 to 70 °C. The line sensitivity of the sensor is 2.8 °C/V.

A 6.4 nW 1.7% Relative Inaccuracy CMOS Temperature Sensor Utilizing Sub-Thermal Drain Voltage Stabilization and Frequency Locked Loop

**Session Chairs:** Andreia Cathelin, STM Electronics; Qiuting Huang ETH Zürich

B1L-3: A-SSCC 2020 Guest Invited Papers

technical paper
