Naval Asset Corrosion and Defect Segmentation Using UNet Architecture

Abstract:

Corrosion poses a significant challenge in the maintenance and upkeep of naval assets, leading to degradation and high cost. Timely and accurate detection of corrosion and other defects are crucial to ensure operational efficiency and system availability. Traditional methods for detection often involve manual inspections, which are time-consuming, prone to human error, and require inspectors with specialized training and expertise.

There is a significant amount of research into automatic detection of corrosion via computer vision algorithms and semantic segmentation that we utilized to combat this problem. Our method makes use of hand-annotated high-resolution images of existing weathered structures (conex boxes) as inputs for a machine learning model to detect basic corrosion, as well as classify additional defects such as paint blistering and cracking. Due to the limited amount of data representing the extended classes, image augmentations were performed to expand our dataset.

When classifying “stuff”, where the defects can be any shape or size, having an extremely high level of precision is necessary. To account for this, a UNet machine learning architecture, which consists of a contracting and symmetric expanding path, was chosen due to its capability of performing precise pixel-level image segmentation with fewer training data requirements. We have experimented with multiple variations of UNet and implemented additional modules like attention and deep supervision in order to increase the overall performance and generalization of the model.

NAML 2024

Naval Asset Corrosion and Defect Segmentation Using UNet Architecture

unet

corrosion

segmentation

poster
