Up-scaling of quantum information processors requires the cryogenic control CMOS devices to be operated in the few millivolt regime. However, MOSFETs show inverse subthreshold slope SS values which saturate well above the theoretical Boltzmann limit at cryogenic temperatures. In addition to this saturation of SS caused by band tailing, inflection degrades SS as a function of the gate voltage. We show gate stack engineering as an approach to counteract those phenomena which facilitate the realization of steep slope cryogenic MOSFETs.

DRC 2022

Interface Engineering for Steep Slope Cryogenic MOSFETs

steep-slope devices

gate-stack modifications

interlayer

band tailing

cryogenic mosfets

inflection

interface engineering

silicon nitride
