Cryogenic computing requires extensive memory and bandwidth. Capacitor-less single transistor DRAM offers larger capacity along with improvement in retention characteristics at cryogenic temperatures. Thyristor RAM (TRAM), in addition to having FinFET form-factor compatibility, benefits from a large on/off ratio (&gt;10^7) and non-destructive read that enable a fast read/write speed (&lt;1ns). In this paper, through TCAD simulations a TRAM is demonstrated for cryogenic applications for the first time and its performance metrics are compared to FB-PDSOI capacitorless-DRAM at cryogenic temperature. A permanent &#39;data 1&#39; retention and more than 10^5s &#39;data 0&#39; retention time is observed at 77K.

DRC 2022

Cryo-TRAM: Gated Thyristor based Capacitor-less DRAM for Cryogenic Computing

cryogenic computing.

tram

capacitor-less dram

thin-capacitively-coupled-thyristor
