The issues related to the failure analysis of 4H-SiC PowerMOSFET failed at EWS (Electrical Wafer Sorting) such as the channel leakage current is investigated. In particular, EWS is carried out in the namely defect free wafers areas monitored at several inline levels. This paper reports on the electrical based methods used to spot macroscopic defects even if they are invisible at optical wafer inspections. In particular, the current separation technique on source and gate terminals allowed to reduce the number of  candidate samples to be investigated

IRPS 2022 Main Conference

Failure analysis addressing method of optically undetected defectivity on 4H-SiC PowerMOSFET epitaxial layer

poster
