In bit patterned media recording (BPMR), to increase the areal density (AD), we must reduce the distance between the magnetic islands. This leads to severe two-dimensional (2D) interference. The 2D interference includes inter-symbol interference (ISI) and inter-track interference (ITI) from the down- and across-track directions, respectively. To combat the 2D interference, we can decompose the ISI and ITI into the serial model [1]. However, in [1], the authors just use the Viterbi algorithm for detection, the detection lacks prior information from the inner detector to the outer detector. In this article, we use the maximum a posteriori (MAP) algorithm to supply the prior information from the inner detector to the outer detector. Our proposed model is presented in Fig. 1. We use the serial GPR target in [1]. The received signal is feed to the horizontal detection (using MAP algorithm). Each output data of the horizontal detection &lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] includes six probability values of 6 symbols, respectively. We use the argmax(&lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]) to convert the signal &lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] into the hard output &lt;i&gt;b&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]. &lt;i&gt;b&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] is used to extract the noise information and create the soft output signal [2] (i.e., &lt;i&gt;soft&lt;/i&gt;(&lt;i&gt;b&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;])). The signal &lt;i&gt;soft&lt;/i&gt;(&lt;i&gt;b&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]) is detected by the MAP algorithm in the vertical detection and creates the probability of -1 or +1 in &lt;i&gt;s&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]. Then, &lt;i&gt;s&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] and &lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] are entered to the log detection. We calculate the product of the probability of +1 from &lt;i&gt;s&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] and the sum of the probability from the symbols, which contains the input +1, in &lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]. This product is assigned to a numerator. Then, we calculate the product of the probability of -1 from &lt;i&gt;s&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] and the sum of the probability from the symbols, which contains the input -1, in &lt;i&gt;r&lt;/i&gt;[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;]. This product is assigned to a denominator. Finally, we calculate &lt;i&gt;d&lt;/i&gt; = log(numerator/denominator). If &lt;i&gt;d&lt;/i&gt; ≥ 0, â[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] = 1 and if &lt;i&gt;d&lt;/i&gt; &amp;lt; 0, â[&lt;i&gt;j&lt;/i&gt;,&lt;i&gt;k&lt;/i&gt;] = 0. The results of our proposed model are presented in Fig. 2. We compare our model with the serial detection in [2]. Our proposed model improved the bit error rate (BER) performance of the serial detection.

![](https://assets.underline.io/uploads/markdown_image/1/image/31b45afd062763fbaee54fb1167b8174.jpg)

Fig.1 Our proposed model.

![](https://assets.underline.io/uploads/markdown_image/1/image/0ef7ea1ba565b056af38a507b0793812.jpg)

Fig. 2 BER performance of the proposed model.
