United States

A recent study shows that the magnetic entropy changes of Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; nanostructure depend on the morphology and it varies from - 8.7 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for nanotubes to - 20 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for the rod. Several attempts have been made to study the magnetocaloric effect (MCE) on different morphology but comparative study on morphology dependent MCE is missing. Here we investigate the MCE of Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; nanoparticles of different morphology. Single-phase Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; nanoparticles were synthesized via the hydrothermal method and a homogeneous precipitation method followed by heat-treated in the air at 1100&lt;sup&gt;O&lt;/sup&gt;C for 12h. Four Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; nanoparticles of different shapes viz. bulk, rod, spheres, and plate were prepared. The morphology of the samples was analyzed using a scanning electron microscope (SEM). The SEM images of synthesized Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; showed fine 1D nano-rods, 2D nano-plates-like architecture prepared via hydrothermal method while hollow nanosphere morphology was achieved with a homogeneous precipitation method. The phase identification and lattice parameter of the powders were performed using x-ray diffraction which showed the presence of a highly crystalline single phase cubic crystal structure. Magnetic measurements were performed from 5 to 100K and magnetic field up to 50kOe. The material demonstrated typical paramagnetic behavior in the whole measured temperature region. The M-H data in the temperature range of 3–30 K is used to calculate the isothermal magnetic entropy change. The maximum value of ΔSm for 50 kOe field change at 5K is 11.2 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for the nanoplate sample, 9.4 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for the nano-rod, and 9.2 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for the nano-sphere, and 10.7 J kg&lt;sup&gt;−1&lt;/sup&gt; K&lt;sup&gt;−1&lt;/sup&gt; for Bulk. The large ΔSm could be attributed to the surface area and surface geometry of the sample. More surface area indicates more surface spins that enhanced magnetization value. These results show the Gd&lt;sub&gt;2&lt;/sub&gt;O&lt;sub&gt;3&lt;/sub&gt; nanoplates are promising materials for low-temperature application.&lt;br/&gt;Work at SUNY, Buffalo State was supported by the startup fund from SUNY Buffalo State College and the Undergraduate Research Office, Buffalo State.

2022 Joint MMM-INTERMAG

Study the magnetocaloric properties of shape-dependent nanostructured Gd2O3: Nanoplates, Nanorods, and Nanospheres

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

A recent study shows that the magnetic entropy changes of Gd2O3 nanostructure depend on the morphology and it varies from - 8.7 J kg−1 K−1 for nanotubes to - 20 J kg−1 K−1 for the rod. Several attempts have been made to study the magnetocaloric effect (MCE) on different morphology but comparative study on morphology dependent MCE is missing. Here we investigate the MCE of Gd2O3 nanoparticles of different morphology. Single-phase Gd2O3 nanoparticles were synthesized via the hydrothermal method and a homogeneous precipitation method followed by heat-treated in the air at 1100OC for 12h. Four Gd2O3 nanoparticles of different shapes viz. bulk, rod, spheres, and plate were prepared. The morphology of the samples was analyzed using a scanning electron microscope (SEM). The SEM images of synthesized Gd2O3 showed fine 1D nano-rods, 2D nano-plates-like architecture prepared via hydrothermal method while hollow nanosphere morphology was achieved with a homogeneous precipitation method. The phase identification and lattice parameter of the powders were performed using x-ray diffraction which showed the presence of a highly crystalline single phase cubic crystal structure. Magnetic measurements were performed from 5 to 100K and magnetic field up to 50kOe. The material demonstrated typical paramagnetic behavior in the whole measured temperature region. The M-H data in the temperature range of 3–30 K is used to calculate the isothermal magnetic entropy change. The maximum value of ΔSm for 50 kOe field change at 5K is 11.2 J kg−1 K−1 for the nanoplate sample, 9.4 J kg−1 K−1 for the nano-rod, and 9.2 J kg−1 K−1 for the nano-sphere, and 10.7 J kg−1 K−1 for Bulk. The large ΔSm could be attributed to the surface area and surface geometry of the sample. More surface area indicates more surface spins that enhanced magnetization value. These results show the Gd2O3 nanoplates are promising materials for low-temperature application. Work at SUNY, Buffalo State was supported by the startup fund from SUNY Buffalo State College and the Undergraduate Research Office, Buffalo State.

poster

Recently, SmFe11Ti-based compounds with the ThMn12 crystal structure have been widely studied as a candidate for new permanent magnets due to their excellent intrinsic magnetic properties. Although those compounds have a high anisotropy field (12 T), the actual coercivity is less than 10% of their anisotropy field 1. In general, it is well known that fine precipitates corresponding to the size of the domain wall (several nm to several tens of nm) increase the coercivity of hard magnetic materials by acting as the domain wall pinning site. The addition of C to the SmFe11Ti alloy may result in TiC precipitates in the matrix, and subsequent changes in the coercivity can be expected. In this study, SmFe11Ti alloys containing different amount of C atoms were fabricated by the melt-spinning method to investigate the effects of C atoms on the microstructures and magnetic properties. SmFe11Ti1+xCx (x = 0, 0.05, 0.1, 0.2) alloys with the ThMn12 crystal structure was successfully fabricated by the melt-spinning method and subsequent heat treatment. The optimum heat treatment condition was found to be 850°C for 15 minutes, and the coercivity was shown to be about 6.2 kOe regardless of the C content (Fig. 1). In order to understand these results, the microstructural analysis was performed. It was found that the matrix had the ThMn12 crystal structure and the average grain size was about 30 nm in all samples regardless of the C content (Fig. 2). In these samples, coarse TiC grains (&gt;100 nm) instead of TiC nano-precipitates were formed independently from the matrix. This result explains the reason why the coercivity did not change. Thus, the experimental conditions for obtaining the precipitates are under investigation.


![](https://assets.underline.io/uploads/markdown_image/1/image/75746d30b79db84128662e894a5853fe.jpg)


Fig. 1 Coercivity measured at 2.5 T of SmFe11Ti1+xCx (x = 0, 0.5, 0.1, 0.2) alloys heat treated at 850°C for 15 minutes.


![](https://assets.underline.io/uploads/markdown_image/1/image/4b02a146f9f1f24e4dc7ba739af1ff8b.png)

Fig. 2 Microstructures of SmFe11Ti1.2C0.2 sample heat treated at 850°C for 15 minutes. (a)Bright field image using Transmission Electron Microscopy. (b)Dark field image and corresponding EDS mapping image using Scanning Transmission Electron Microscopy. The grains which was shown in dark contrast on the image was region that Ti and C was concentrated.

The effect of C addition on the magnetic properties and microstructures of nanocrystalline SmFe11Ti alloy

Research on rare-earth-free permanent magnet materials have attracted much attention due to the limited supply and high price of the rare-earth metals used in current state-of-the-art permanent magnets. MnBi and MnBi-based magnets have been investigated as prospective rare-earth-free magnets because the magnetic anisotropy of MnBi increases with increasing temperature reaching a maximum value at 590 K. However, segregation of Bi during synthesis of MnBi is one of the issues which reduces the saturation magnetization. We have found that MnBi synthesized in carbon environment substantially reduces the amount of Bi segregation improving its saturation magnetization. We have synthesized Mn55Bi45 and Mn55Bi45C samples using arc melting and high vacuum annealing. The room temperature x-ray diffraction patterns indicate that both Mn55Bi45 and Mn55Bi45C crystallize in the hexagonal NiAs crystal structure (Low temperature phase, LTP). The X-ray diffraction pattern also indicates that the amount of Bi segregation in Mn55Bi45C is less than that in MnBi. As shown in Fig. 1 below, the high field (3T) magnetization measured at room temperature are 61 emu/g and 66 emu/g for Mn55Bi45 and Mn55Bi45C, respectively. There is small increase in the value of anisotropy constant due to carbon doping. In order to find the possibility of carbon occupying the MnBi lattice, we have carried out first principles calculations of MnBi alloy as well. The conclusions of the first principles calculation and experimental data on structural and magnetic properties of Mn55Bi45 and Mn55Bi45C will be presented. This research is supported by South Dakota-NASA EPSCoR Research Initiation Grant no 80NSSC19M0063.

![](https://assets.underline.io/uploads/markdown_image/1/image/e0f6f2e16ebf3f5ccde46e9f75d13c25.jpg)

Fig. 1: Isothermal magnetization curves M(H) for Mn55Bi45 and Mn55Bi45C measured at 300 K. Inset shows the M(H) curve for Mn55Bi45C after aligning in magnetic field.

Modifying magnetic properties of MnBi with Carbon: An experimental and theoretical study

1.Background Rare earth permanent magnets, i.e., Nd2Fe14B and Sm2Co17, have been used in spacecraft motors. However, the direct atomic displacement in the rare earth permanent magnets’ so-called knock-on damage occurs via cosmic rays [1]. If the knock-on atom does not return to a normal lattice position, the empty lattice point becomes atomic vacancy, so-called a point defect. As a result, the rare earth permanent magnets degrade in magnetic properties and demagnetize, and it could also cause cascade damages. We studied Nd2Fe14B with point defects by first-principle calculation to show how the point defect affects its magnetic properties. 2. Calculation method and models Formation energies and magnetic properties were calculated by the first-principles calculations based on density functional theory, which is implemented in the VASP code with GGA + U method (U = 6 eV) [2]. The cut-off energy was 700 eV, k-point mesh was set to and lattice constants were determined based on the experimental values [3]. A point defect of Nd was assumed to be generated when the interatomic bond in the Nd2Fe14B crystal was cut by the collision of radiation particles with Nd atoms (Fig. 1). The generation processes of point defects of B and Fe were assumed to be the same as Nd. Thus the point defect formation energy was defined as the energy difference before and after the collision as shown in Eq. 1. Eform=(Edef+Eiso)-Eperfect (1) where Eper, Edef and Eiso are the total energies of electrons in a perfect crystal, a crystal with a point defect, and an isolated atom, respectively. 3. Results First, we confirmed that the magnetic moments of the calculation for the perfect crystal and experiment were similar (Table I). Subsequrntly, we found that only the crystal with the point defect of B increased the magnetic moment. We also found that the point defect formation energies of Fe were lower than those of B and Nd and the point defect formation energies of B and Nd were similar.

![](https://assets.underline.io/uploads/markdown_image/1/image/aad867ae5234f598c10ca41a8650f875.jpg)

Fig.1 Calculation models for point defect formation energy of Nd in Nd2Fe17B.


![](https://assets.underline.io/uploads/markdown_image/1/image/590f8f080de1faeb3e880ca5a596de16.jpg)

Table I. Magnetic moments and point defect formation energies

First-principles study of rare earth permanent magnets with point defects created by radiation

Recently, more attention has been paid to developing rare earth free permanent magnets. (Fe0.7Co0.3)2B with tetragonal structure shows good intrinsic hard magnetic properties. It has a large saturation magnetization (Js=13 kGs), a high Curie temperature (Tc=940 K), and a moderate uniaxial magneto-crystalline anisotropy (MCA) field (HA= 7.7 kOe) [1-4]. In addition to the good intrinsic properties, the hard magnetic properties such as coercivity are also sensitive to microstructure. In particular, the coercivity reduces sharply upon the existence of the low MCA regions in microstructure, which favors the nucleation of the magnetic domain for the magnetization reversal. There always exist some local structural defects in real magnets, such as chemical composition fluctuation, local strain, and even the second impurity phase. In this work, the sensitivity of MCA to composition fluctuation and structural defects has been studied by a first-principles DFT calculation. The calculated MCA energy (Emca) of (Fe0.7Co0.3)2B with perfect structure is 0.125 meV/f.u. A fluctuation of cobalt content of 10%, or 1% isotropic lattice strain (Fig.1), or 2% tetragonal distortion will cause a reduction of Emca up to 30% in (Fe0.7Co0.3)2B. The spin-resolved MCA analysis indicates that spin-up and spin-down electrons contribute positively to Emca while the spin mixing has a negative contribution (Fig.1). The interplay of these different contributions results in optimized chemical composition or geometrical structure to maximize MCA. Micromagnetic simulation indicates that the coercivity decrease from 2.2 kOe to 1.0 kOe in an isotropic magnet of (Fe0.7Co0.3)2B with an average grain size of 30nm by considering the existence of randomly distributed local reduction of MCA energy up to 30%. This work is supported by the Critical Materials Institute (CMI), an Energy Innovation Hub funded by the U.S. Department of Energy (DOE), Office of Energy Efficiency and Renewable Energy, Advanced Manufacturing Office. Ames Laboratory is operated for the U.S. DOE by Iowa State University under Contract No. DE-AC02-07CH11358.

![](https://assets.underline.io/uploads/markdown_image/1/image/c11d0f0079ff1d8d06c4d6f00a36a5d9.jpg)

Calculated spin-resolved- and total- magnetocrystalline anisotropy energy as a function of lattice strain in (Fe0.7Co0.3)2B.

Robustness of magneto-crystalline anisotropy and its effect on coercivity in (Fe0.7Co0.3)2B

Magnetic refrigeration (MR), exploiting the adiabatic demagnetization phenomena, is preferable over conventional gas-compression based technology due to its low cost and high efficiency along with environment-friendly method [1-3]. Recently, earth-abundant Mn-based alloy, Mn5Ge3 has emerged as a potential alternative with reasonably high relative cooling power (RCP) which is the centre of the present study [4]. Concerning the technological applications, the role played by the size-reduction (macro to micro-scale) on the engineering of innovative devices is still in its early age. In this context, Mn5Ge3 ribbons are synthesized using the melt spinning technique. The temperature and field-dependent dc magnetization are measured with physical properties measurement system (Quantum design, 8T). The M (T) curve at 1 kOe shows a sharp ferromagnetic ordering at TC ~ 304 K. Furthermore, the M (H) hysteresis loop at 5 K reveal the typical soft ferromagnetic behaviour with saturation magnetisation (MS) of 136 emu/g with approximately zero hysteresis loss which is highly preferential for MR technology. From magnetic isotherms, the magneto-caloric effect is studied in the wide temperature range of 250-360 K. Using the Maxwell equation, Isothermal magnetic entropy change (ΔSM) is calculated as 5 J/Kg-K at 5 T applied field [See Fig 1]. From inset of Fig. 1, It is quite apparent that all the normalized entropy curves with various ΔH values collapse into a single curve, confirms second order magnetic phase transition. Next, we calculate another parameter such as RCP = ΔSm|max × δTFWHM, where δTFWHM is the span for half to maxima of ΔSm (T) curve around a magnetic transition for practical utilization in MR. The RCP value is obtained as 295 (600) J/kg for a field change of 3 (5) T which is significantly larger than 201.3 J/kg (3 T) as observed in an earlier Mn5Ge3 study [5]. Hence, a large RC value makes the Mn5Ge3 ribbon highly promising for magnetic refrigeration application near room temperature.

![](https://assets.underline.io/uploads/markdown_image/1/image/b4bb7f645e496a7395e89ca7a488d9ca.jpg)

The temperature dependence of -ΔSm in field range of 0.5 - 3T (ΔH = 0.5 T) and 4 - 8T (ΔH = 1 T). The inset shows normalized -ΔSm as a function of the rescaled temperature (θ).

Enhanced refrigerant capacity in Mn5Ge3 melt spun ribbon near room temperature

Magnetic cooling, based on the magnetocaloric effect (MCE), offers many advantages over traditional compressor-based refrigeration. Among many promising materials, the (Mn,Fe)2(P,Si) family of compounds attracts broad attention due to the non-toxic composition, large magnetocaloric effect, tunable Curie Temperature (Tc) and limited thermal hysteresis (ΔThys). The stoichiometry of the quaternary alloy (Mn,Fe)2(P,Si) has a significant impact on the magnetocaloric performance. Additionally, the magnetocaloric response of the (Mn,Fe)x(P,Si) system is highly sensitive to the heat treatment conditions. For the Fe-rich (Mn,Fe)x(P,Si) (2.00 ≥ x ≥ 1.80) melt-spun ribbons, we investigated the phase purity as a function of starting composition and annealing temperature. For a first batch, annealed for 2h at 1373 K, we found with decreasing M/NM ratio from 2.00/1 to 1.90/1 an increase in Tc from 251.3 to 310.1 K and a decrease in ΔThys from 33.3 to 8.3 K. These changes were accompanied by a decreasing amount of the metal-rich (Mn,Fe)3Si impurity phase. A further decrease of the M/NM ratio leads to a rapid reduction of Tc to 178.5 K and an increase in hysteresis to 75.7 K. Along with these changes, the formation of the non-metal (Mn,Fe)Si impurity phase was observed. In order to investigate the effect of the heat treatment, ribbons were annealed at 1313 and 1433 K. The magnetic entropy change (ΔSm) and ΔThys increase with increasing annealing temperature, indicating the enhancement of the First Order Magnetic Transition (FOMT). The formation and composition of the (Mn,Fe)3Si impurity strongly depend on the annealing conditions, as evidenced by SEM/EDS analysis. The change in the annealing temperature caused a significant change in the composition and amount of the (Mn,Fe)3Si impurity phase. These changes were accompanied by the enlargement of grains and grain boundaries. The (Mn,Fe)Si impurity phase segregated in the form of micro-sized inclusions. Unlike (Mn,Fe)3Si, the (Mn,Fe)Si impurity appeared stable and remained strongly Fe and Si-rich for all annealing temperatures.

Improving the Magnetocaloric Response of Fe-rich (Mn,Fe)2(P,Si) Alloys

Gadolinium is the simplest material with a strong magnetocaloric effect close to room temperature (Tc = 293 K) and no thermal hysteresis [1], making it an ideal test-bench material for magnetic refrigeration and energy harvesting prototypes [2,3]. Gd ribbons of thickness 36-215 μm were prepared by cold-rolling [4] while films of thickness 20-150 μm were deposited by evaporation onto dimpled Hastelloy substrates [5]. More recently, films of thickness in the µm range were made by magnetron sputtering [6,7]. Here we present a study of Gd films of thickness in the range 3.5 - 40 μm, deposited by triode sputtering onto Si substrates at RT or 400°C, with Ta buffer and capping layers. As has been reported in magnetron sputtered films [7], our triode sputtered films can be removed from the substrate to produce free-standing films, and peel-off is easiest for films deposited at elevated temperature. Films were characterized structurally (optical and Scanning Electron Microscopy, XRD), magnetically (VSM-SQUID, extraction magnetometer) and mechanically (interferometer, nanoindenter). An SEM image of the fractured cross section of a 20 µm thick film deposited at 400°C is shown in Fig. 1, together with θ-2θ XRD patterns from the upper and lower surfaces of the film. It can be seen that the film texture changes from (00l) at the lower surface to (103) at the upper surface. A spin-reorientation transition is clearly seen in the M(T) curve of a 3.5 µm thick film, while it becomes smeared in thicker films (Fig. 2), owing to the evolution in crystallographic texture. In this presentation we will report on the influence of film thickness and deposition temperature on the structural, magnetic and mechanical properties of Gd films, which are being developed for integration into micro-scaled thermal energy harvesting devices [3]. Acknowledgement: This research has received funding from the French National Research Agency under the HiPerTherMag project (ANR-18-CE05-0019).

![](https://assets.underline.io/uploads/markdown_image/1/image/dd535808ff17c217e3a7ead00118fb60.jpg)


Fig. 1 Left: SEM image of a 20 µm thick Gd film deposited at 400 °C. Right: θ-2θ XRD spectra from the upper and lower surfaces of the film, following peel-off from the substrate.


![](https://assets.underline.io/uploads/markdown_image/1/image/f29d014564fd1b808054343a926d5a44.jpg)

Fig. 2 Magnetization vs temperature, measured under 50 mT, of Gd films deposited at 400°C.

Structural, magnetic and mechanical properties of Gd films

For the regular machines, the pole-pairs of machine stators and rotors are identical, where the torque is produced by the single working harmonic from the rotor and stator magnetic fields. During the last hundred years, numerous studies have been done to enhance the working harmonics and weaken the non-working harmonics, so as to acquire the sinusoidal air-gap magnetic fields and improve the quality of torque. The presentation will provide a view on electrical machines from the third eye –Flux Modulation point of view. As a new type of machine, the flux modulation PM machines, have drawn more and more attention due to their great torque density capability. Compared with regular PM machines, the pole-pairs of armature windings and rotor PMs in flux modulation machines are different, where the torque is generated by multiple working harmonics of PM magnetic fields and armature magnetic fields. Under the same electric and magnetic loadings, the flux modulation machines can acquire nearly double torque density of regular PM machines. This presentation will introduce flux modulation fundamental operation principles, machine main features, and topologies including multiple magnetomotive force harmonic machines, multiple permeance harmonics machines and double-modulation machines. Applications, challenges, and research opportunities will be discussed as well.

Flux Modulation Machines – Innovation & Beyond

Arguably the pinnacle of motorsport are race cars and therefore an excellent showcase for new technologies from the different areas of automotive systems. Racing “should” utilize components that are beyond the state-of-the-art and within the Advanced Electromagnetics Group (www.ae-grp.nl) we are providing powertrains and test systems for the design, testing, and validation of high-tech and innovative race car powertrains for all-electric racing championships. These e-racing championships are not something that is started in the 21st century. No, already in 1899 Belgian driver and engineer Camille Jenatzy drove flat out in his torpedo-shaped ‘La Jamais Contente’ (‘never satisfied’) in a sparsely populated area to the northwest of Paris and became the first person to reach more than 100 km/h in a car [1]. Even though the electric powertrain failed to dominate the car industry in the twentieth century, 115 years later in 2014, Formula E appeared with its first-ever race in Beijing, China. Founded in 2011, this is an all-electric championship that showcases around the world a combination of sustainability claims, entrepreneurial spirit and commercial savviness. In Formula E all cars are aerodynamically similar but have some technological differences. Formula E was helped by the automotive world entering the ‘Dieselgate’ or ‘Emissionsgate’ in 2015. Despite these achievements, Formula E still struggles to showcase the technology to the public. Manufacturers are accumulating ever more know-how on electric cars, where Formula E may even turn out to be a hindrance in terms of innovative solutions. As such, the rulebook has to keep track of what is in it for the OEMs that participate. As an example, the Porsche Taycan model has a peak charging capacity of 270 kW and is one the fastest electric vehicles currently on the market. However, Formula E 2020 vehicles charge at a peak rate of 100 kW. Some motorsport fans have mocked the city based racetracks, and Formula E cars were nicknamed ‘hairdryers’ for not having the classic racing sound. In the beginning drivers had to change vehicles during the race because of the batteries. Especially discussed was the ‘Fanboost’ (an e-voting service providing your favourite driver with extra power in the race). However, what ever is said it is a racing class that is on the move and aim to adapt new technologies. For example, in the FIA Formula E season 3, the VENTURI team used an inverter with insulated-gate bipolar transistors/ Silicon Carbide Schottky Barrier Diode module. It reported a 2 kg weight reduction and 19% size reduction compared season 2 inverter with IGBT module [2]. In the next season a full Silicon Carbide module was used, where the inverter is capable of operating at 150°C junction temperature with a reduced switching losses of 75% compared to the IGBT solution. This opens the path for integrated motor that will use the high power density of SiC devices, and their high efficiency and cooling loop simplification thanks to the high temperature operation capability of SiC devices [3]. These electrical machines and drives not only have to withstand large forces, but also need to be designed to account for many advanced innovations. High-torque densities are a key requirement in traction machines. Using a multiple air gap design can achieve up to 60 percent higher torque density relative to single airgap machine. This talk will provide an overview of advanced powertrain technologies that aided to progress vehicle racing. By a careful choice and sizing of powertrain components coupled with an optimal energy management strategy from the batteries, attractive racing will be here to stay.

Formula E: Electric Machines and Drives Strategy

Reducing the rate of CO2 emissions for hybrid electric vehicles (HEV) and improving the autonomy for full battery electric vehicle (BEV) constitute major challenges for motor manufacturers. That can be done by losses reduction in each part of the electric powertrains. In the electric motors, using high grades magnetic material and optimal design allows reducing iron losses in the important area of the Torque-Speed plane. That is why segmented stator cores mixing grain oriented electrical steel (GOES) and non-oriented electrical steel (NOES) constitute a serious way of improvement. The goal of the paper is to present the existing structures with, for instance GOES teeth and NOES yoke, and to analyze the contribution of the high grade steel in the automotive motor improvement, in terms of efficiency, masse and volume. GOES has strong advantages in terms of iron losses and flux density at saturation, when it is magnetized in the Rolling Direction (RD). GOES has the drawback of being very anisotropic and the performance is not so interesting in the Transverse Direction, compared to NOES, especially in term of iron losses at high induction and high operational frequencies [1]. That implies to adapt the machine geometry to the specificities of this steel [2] [3] [4]. Another disadvantage of GOES is the sensitivity to the manufacturing processes: bending, cutting, compacting… [3]. From a micro-structural point of view, cutting the sheets causes a destruction of the grains close to the cutting border. At a macroscopic scale, that reduces the magnetic performance, depending not only on the cutting technique but also the dimensions of the sheet [5]. First, in the full paper, the authors present the existing magnetic circuit structures and how the constraints linked to the high anisotropy ratio has been taken into account. The electric motor analyzed mixes GOES teeth and NOES yoke, as shown in Fig.1. Second, the question of the modelling is posed. The full analytic simulation of the motor is not really adapted taking into account the complexity of the anisotropy. The Finite Element software applications integrate now both anisotropy and saturation, but not always in 3D. The strong difficulty is that the magnetic characteristics differ as a function of the magnetization angle. As a result, the results are not enough accurate in term of flux density distribution. The loss models, when they are implemented for GOES, are not reliable when the sheet is magnetized in multiple directions. Third, in order to analyse the contribution of the elements constituting the magnetic circuit, the authors propose a device, shown in Fig. 2, for numerical and experimental tests. It is designed in order to reproduce the phenomena occurring in the electrical motors, especially in the region between the teeth and the yoke. To do that, it combines two Epstein frames modified to magnetize different magnetic structures. The goal is to analyse the flux densities in the magnetic circuit and the iron losses, depending on several parameters as different geometries of junctions between the segments. The angle and the depth of insertion of the teeth into the yoke will be analysed. It allows also to evaluate the effect of the flux passing not directly in a teeth, but only the yoke. That happens in fractional slot permanent magnet machines and, in that case, the TD is fully solicited. Then, the nature and the grades of the materials will be tested with 0,20mm GOES and NOES. Effect of manufacturing will also be shown with experimental test made with cut laminations. Fourth, an existing full NO steel reference motor will be numerically compared with an improved machine made with mixed NOES and GOES. The comparison will be made on local quantities (flux density, etc) as well as on integral quantities (Flux, EMF, Electromagnetic torque and losses). The authors will also present simulation results showing the efficiency improved by the use of GOES.

![](https://assets.underline.io/uploads/markdown_image/1/image/aed73ebd63bf37d4e50d037464f03e5c.jpg)

Fig.1

![](https://assets.underline.io/uploads/markdown_image/1/image/548defbb0b245a7f85b58ec80f02f477.jpg)

Fig. 2

Study the magnetocaloric properties of shape-dependent nanostructured Gd2O3: Nanoplates, Nanorods, and Nanospheres
