The current loop is a fundamental building block of cylindrically symmetric magnetic calculations. However the off axis field magnetic involves the subtraction of elliptical integrals and second kind which is computationally expensive, hard to manipulate in equations and difficult to visualize. By doing a different binomial series expansion on the original loop integral a series solution is created, which can be simplified to a set of approximations with useful characteristics: exactly correct at along the axis, and at distance, while at the current loop itself the relative error is limited, computational simple, easy to visualize the behavior and symmetry. Figure 1 shows for the radial field the first and second order fits where the parameters are optimized to give minimize the relative peak error. Note the symmetry that occurs by expressing as function of W, allowing maximum relative errors of 0.025 for 1&lt;sup&gt;st&lt;/sup&gt; order and 2.9E-4 for second order (Figure 2 shows 2&lt;sup&gt;nd&lt;/sup&gt; order relative error in all space). For axial field (Figure 1) the first order, due to the subtraction the accuracy is only modest but the 2&lt;sup&gt;nd&lt;/sup&gt; order has a 9E-4 maximum relative error along, with zero error at the loop on the z=0 plane. The axial field relative error stays low within the loop but outside does, and stays low for any h until it falls to 1% of the z=0 plane value, then lose accuracy as z is near where the field direction reverses sign due to slight differences in the zero crossing predicated coordinate, increasing again in accuracy as z further from the reveal. Higher order approximations add more W terms and see increasing accuracy – for radial 3&lt;sup&gt;rd&lt;/sup&gt; order 1.8E-5, 4&lt;sup&gt;th&lt;/sup&gt; 2,3E-6, 5&lt;sup&gt;th&lt;/sup&gt; 4.9E-7, while axil goes as 3&lt;sup&gt;rd&lt;/sup&gt; 4.6E-5, 4&lt;sup&gt;th&lt;/sup&gt; 6E-6. Note that the simplicity of these functions suggests new ways combining loops to optimize such things as field uniformity. The final paper will show how these approximations are created, plus more details on the error distributions of these and higher orders.

![](https://assets.underline.io/uploads/markdown_image/1/image/347293d7d5dee787ac314cbdc7b3a7ca.jpg)

Figure 1: Current loop off axis field approximations of order 1 and 2

![](https://assets.underline.io/uploads/markdown_image/1/image/6324541f77db2ddbf4cd30f9337b8df7.jpg)

Figure 2: Radial field 2nd order approximation relative error

2022 Joint MMM-INTERMAG

Current Loop Off Axis field Approximations with Excellent Accuracy and Low Computational Cost

The 15th Joint MMM-INTERMAG Conference (2022 Joint) is sponsored jointly by AIP Publishing and the IEEE Magnetics Society. Members of the international scientific and engineering communities interested in recent developments in fundamental and applied magnetism are invited to attend and contribute to the technical sessions. The technical program will include invited and contributed papers in oral and poster sessions, invited symposia, a plenary session, and an evening session, with about 1500 presentations overall. This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The 2022 Joint Conference will offer both in-person and prerecorded on-demand content.

For tickets to the event, please register at the following link: https://magnetism.org/register

Please register for the Joint MMM-Intermag conference to join the event.

This Conference provides an outstanding opportunity for worldwide participants to meet their colleagues and collaborators and discuss developments in all areas of magnetism research.

The current loop is a fundamental building block of cylindrically symmetric magnetic calculations. However the off axis field magnetic involves the subtraction of elliptical integrals and second kind which is computationally expensive, hard to manipulate in equations and difficult to visualize. By doing a different binomial series expansion on the original loop integral a series solution is created, which can be simplified to a set of approximations with useful characteristics: exactly correct at along the axis, and at distance, while at the current loop itself the relative error is limited, computational simple, easy to visualize the behavior and symmetry. Figure 1 shows for the radial field the first and second order fits where the parameters are optimized to give minimize the relative peak error. Note the symmetry that occurs by expressing as function of W, allowing maximum relative errors of 0.025 for 1st order and 2.9E-4 for second order (Figure 2 shows 2nd order relative error in all space). For axial field (Figure 1) the first order, due to the subtraction the accuracy is only modest but the 2nd order has a 9E-4 maximum relative error along, with zero error at the loop on the z=0 plane. The axial field relative error stays low within the loop but outside does, and stays low for any h until it falls to 1% of the z=0 plane value, then lose accuracy as z is near where the field direction reverses sign due to slight differences in the zero crossing predicated coordinate, increasing again in accuracy as z further from the reveal. Higher order approximations add more W terms and see increasing accuracy – for radial 3rd order 1.8E-5, 4th 2,3E-6, 5th 4.9E-7, while axil goes as 3rd 4.6E-5, 4th 6E-6. Note that the simplicity of these functions suggests new ways combining loops to optimize such things as field uniformity. The final paper will show how these approximations are created, plus more details on the error distributions of these and higher orders.

![](https://assets.underline.io/uploads/markdown_image/1/image/347293d7d5dee787ac314cbdc7b3a7ca.jpg)

Figure 1: Current loop off axis field approximations of order 1 and 2

![](https://assets.underline.io/uploads/markdown_image/1/image/6324541f77db2ddbf4cd30f9337b8df7.jpg)

Figure 2: Radial field 2nd order approximation relative error
