While InP heterojunction bipolar transistor technologies show continuous improvement in terms of RF performances, the accurate characterization of these THz transistors is crucial to assess the cut-off frequencies as well as to precisely extract and validate the device compact model, thus enabling millimeter and sub-millimeter-wave IC design. On-wafer measurements are particularly difficult beyond 110 GHz since unwanted parasitic effects become predominant and may mask the intrinsic behavior of the nanoscale device. A such high frequencies, two strategies may be adopted and combined in order to perform accurate on-wafer device measurements at submillimeter-wave frequencies: i) optimizing the test structures’ design in order to minimize the parasitics, ii) developping on-wafer calibration standards on the same substrate as the device to characterize. Coupled with electromagnetic simulation for the test structures design optimization and the measurement&#39;s validation, these strategies proved to be efficient for the characterization of InP passive devices up to 500 GHz and InP DHBT up to 330 GHz.
