Millimetre-wave frequency synthesis for RADAR ICs can rely on frequency multiplication. Here the local-oscillator signal – whether a frequency chirp for FMCW or a fixed carrier for PMCW – is first synthesized by a lower-frequency PLL. In case of FMCW, a two-point PLL-based frequency modulator can deliver a large-bandwidth fast chirp, which boosts range resolution and maximal detectable speed. The lower-frequency PLL signal is then distributed and multiplied in frequency at each antenna path. Such a multiplication can be based on harmonic boosting or subharmonic injection locking. All these techniques, which modulate or multiply frequency, are introduced and demonstrated through some implementations in advanced CMOS.

ESSCIRC ESSDERC Educational Events

Frequency synthesis for mm-wave radars

frequency modulation

frequency multiplication

frequency synthesis

mm-wave

cmos

radar
