At ICCAD20, Tim from Google presented the paper titled &quot;The Missing Pieces of Open Design Enablement: A Recent History of Google Efforts&quot; documenting roadblocks preventing fully open source ICs creation.

In less than a year the world has already rapidly changed thanks to Google releasing a fully open source, manufacturable 130nm PDK with open source tooling and no-cost MPW shuttle program!

This talk will cover the success of Google investments in the open source IC space and the resulting huge explosion in open down to the transistor IC parts (including all of the RTL, tooling &amp; PDK). It will also include exciting new annoucements and how new people can get involved.
