Design of 3D ICs is mainly done in separated design environments for each tier, assuming that communication channels between tiers are user-defined and fixed at the beginning of the design process1,2. Suitable for 3D stacking based on TSV or Hybrid Bonding technologies because of the low granularity of these 3D interconnect elements, this methodology becomes more difficult to apply to 3D sequential technologies once trying to integrate Monolithic Inter-tier Vias (MIV) with higher density (around 1.108 vias per mm2). In this paper, we describe a methodology to create a unified design environment, which includes several technologies attached to different tiers. Main advantage of this methodology is that designing a 3D circuit may no more require several design environments, thus simplifying simulations, verifications and layout finishing.
