**Please read the paper on the following link:**

https://1worldcontent.com/ess/9212.pdf

**Abstract:**

The goal of this work is the design, realization, and characterization of a pixel-level front-end in 0.15μm CMOS technology, that allows to directly convert in the digital domain the weak output signal from the Field-Effect Transistor (FET) TeraHertz (THz) detector, in a noise-efficient way. The chosen architecture is a Continuous-Time Sigma-Delta Incremental Analog-to-Digital Converter (CT ΣΔ IADC) with a current DAC feedback, chopper technique and digital lock-in modulation. The measured SNR of this interface is 67.45dB, corresponding to an equivalent number of bit (ENOB) of 10.91. The pixel readout area is 0.072mm2, and the power consumption is 65μW from 1.8V supply. The Noise Equivalent Power (NEP) of the THz detector and readout chain is 268pW/√𝐇𝐳. The readout channel Input Referred Noise (IRN) is 1.2μVrms with the FET, and 0.94μVrms for the channel without detector.

ESSCIRC ESSDERC 2021

A 0.94-μVrms Input Noise Pixel-Level Continuous Time ΣΔ IADC Interface for THz Sensing

sigma-delta converter

incremental adc

readout circuit

fet detector

terahertz
