Singapore

Sodium-ion batteries (SIBs) have attracted growing interest as a promising energy storage technique due to their safety, low cost and excellent cycling performance. Among various electrode materials, phthalocyanine complexes (Pcs) is a kind of organometallic complexes (OMCs) with adjustable structure of organic moieties and metal active sites of inorganic moieties that possess promising redox activity in batteries. In this work, we investigate the interaction of Na atoms with CuPc and F16CuPc thin films by in-situ X-ray photoelectron spectroscopy (XPS) and ultraviolet photoelectron spectroscopy (UPS) in an ultra-high vacuum (UHV) system, corroborated by the density functional theory (DFT) calculations. Na atoms are found to interact with inner pyrrole N ahead of outer aza N, for which process is accompanied by the reduction from Cu(II) to Cu(I). Na deposition leads to a charge transfer to CuPc that successfully fills up the lowest unoccupied molecular orbitals (LUMO) of CuPc. The role of fluorine groups is also investigated. F with high electronegativity can attract Na atoms to interact with outer aza N, and the proposed charge transfer from Na to F16CuPc as well as reduction of central Cu are also affected by the intense Na-F interaction. The microscopic-scale insights we obtained from the in-situ XPS and UPS characterization can be applied to other alkali ion-OMCs model systems, and will give comprehensive guidance for designing OMCs with required configurations and advanced features for next-generation energy storage devices.

MATERIALS FOR HUMANITY (MH 21)

Mechanism study of sodium storage in phthalocyanine based electrode materials
