Abstract Body: Cadmium oxide (CdO) is one of the most promising material systems for low-loss infrared (IR) plasmonics to date. Through reactive co-sputtering using high power impulse magnetron sputtering (HiPIMS) and radio frequency (RF) sputtering, doped CdO demonstrates high mobility films with tunable carrier concentrations across a range corresponding to epsilon-near-zero (ENZ) modal frequencies spanning the mid-IR and reaching into the near-IR. Specifically, indium-doped CdO (In:CdO) yields carrier densities ranging between 2x1019 cm-3 and 5x1020 cm-3 while maintaining mobilities between 300-400 cm2/Vs across this range, thus allowing for the widest accessibility of the IR spectrum (1650-5325 cm-1) of a single plasmonic material grown by sputtering. Fully accessing the spectrum of plasmonic applications, including surface plasmon oscillations, ENZ modes, and strong coupling phenomena requires that one maintains these appealing transport properties over a film thickness range spanning a few tens to a few thousands of nanometers. Extensive CdO fabrication experiments using high-power impulse magnetron sputtering reveal a strong dependence of carrier density and mobility on film thickness when thickness drops below 100 nm, a particularly significant range for ENZ modes. We attribute this behavior to well-reported surface charge accumulation and depletion layers caused by Fermi level pinning. In this presentation, we demonstrate the reversal between surface charge accumulation and depletion in In:CdO. Further, we show how these surface effects can influence optical properties, and how they can be controlled by understanding and manipulating CdO defect chemistry. Lastly, we will show preliminary results of plasmonic tunability via ferroelectric switching.

EMC 2021

Mid-Wave to Near-IR Optoelectronic Properties and Epsilon-Near-Zero Behavior in In-Doped CdO

defect chemistry

fermi level pinning

infrared

plasmonics

thin films

optics

### Welcome to the 8th annual workshop on Naval Applications of Machine Learning!

NAML is the premier annual event showcasing current machine learning research relevant to Naval applications. We welcome participation from the defense community, industry, and academia. The NAML workshop is an opportunity for researchers from Navy research and development centers and our partner organizations to exchange technical ideas and to come together as a team.

The goals of NAML are:

* To spread awareness of current machine learning research relevant to Naval applications

* To connect machine learning researchers with experts in military requirements

* To build and strengthen collaborations within the defense research community

Naval Information Warfare Center Pacific is partnering with AFCEA San Diego chapter to host the workshop.

**General Chairs:**

Katie Rainey, Naval Information Warfare Center Pacific

Nicole Isoda, Naval Information Warfare Center Pacific

**[More about NAML 2024](https://sites.google.com/go.spawar.navy.mil/naml/)**

Please log in to explore this event. You need to log in with the email address you registered with. Access credentials have been sent to your email.

Please be sure to check your spam and other email folders if you do not see an email confirmation right away.

Please log in to explore this workshop.

Registration for this workshop has now closed. We appreciate your interest and hope to welcome you at a future event. If you’d like to hear about similar upcoming events, please check our website or join our mailing list.

Registration for this workshop has now closed.

NAML 2024

The 8th annual workshop on Naval Applications of Machine Learning is an opportunity for researchers from Navy research and development centers and our partner organizations to exchange technical ideas and to come together as a team. The goals of NAML are to spread awareness of current machine learning research relevant to Naval applications, to connect machine learning researchers with experts in military requirements and to build and strengthen collaborations within the defense research community.


technical paper

The Electronic Materials Conference (EMC) is the premier annual forum on the preparation, characterization and use of electronic materials. This year’s event will feature a plenary session, topical sessions, a poster session and more.

EMC is coordinated with the Device Research Conference (DRC), which will be held during the same week, from June 20-23. This recognizes the strong interaction between device and electronic materials research and provides fruitful exchange of information between attendees of both Conferences.

![](https://assets.underline.io/uploads/markdown_image/1/image/eb26c24a18d5d1030616afa4f993cf89.png)

<a href="https://www.mrs.org/docs/default-source/meetings-events/mrs-conference-services/2021/emc-2021/2021-emc-program-at-a-glance-6-16-21.pdf?sfvrsn=e39f950c_4">Latest Program-at-a-Glance</a>

<a href="https://drive.google.com/file/d/1eiS1ao4p83VNy8xgHs3Rls7gTQjx7Rc4/view?usp=sharing">Full Program with Abstracts</a>

Abstract Body: Spin-orbit torque (SOT) driven deterministic control of the magnetization state of a magnet with perpendicular magnetic anisotropy (PMA) is key to next-generation spintronic applications including non-volatile, ultrafast, and energy-efficient data storage devices1-3. But field-free deterministic switching of perpendicular magnetization remains a challenge because it requires an out-of-plane anti-damping torque, which is not allowed in conventional spin source materials such as heavy metals (HM)1-3 and topological insulators4 due to system symmetry. The exploitation of low-crystal symmetries in emergent quantum materials offers a unique approach to achieve spin-orbit torque with unconventional form5,6. Here, we report the first experimental realization of field-free deterministic magnetic switching of a perpendicularly polarized van der Waals (vdW) magnet employing an out-of-plane anti-damping SOT generated in layered WTe2 which is a low-crystal symmetry quantum material. The numerical simulations confirm that out-of-plane antidamping torque in WTe2 is responsible for the observed magnetization switching in the perpendicular direction. 1. Miron, I. M. et al. Perpendicular switching of a single ferromagnetic layer induced by in-plane current injection. Nature 476, 189-193, (2011). 2. Liu, L. et al. Spin-Torque Switching with the Giant Spin Hall Effect of Tantalum. Science 336, 555-558, (2012). 3. Liu, L. et al. Current-Induced Switching of Perpendicularly Magnetized Magnetic Layers Using Spin Torque from the Spin Hall Effect. Physical Review Letters 109, 096602, (2012). 4. Mellnik, A. R. et al. Spin-transfer torque generated by a topological insulator. Nature 511, 449-451, (2014). 5. MacNeill, D. et al. Control of spin-orbit torques through crystal symmetry in WTe2/ferromagnet bilayers. Nature Physics 13, 300-305, (2017). 6. Xue, F. et al. Unconventional spin-orbit torque in transition metal dichalcogenide--ferromagnet bilayers from first-principles calculations. Physical Review B 102, 014401, (2020).

Deterministic Switching of a Perpendicularly Polarized Magnet Using Unconventional Spin-Orbit Torques in WTe2
