EMPHATIC (Experiment to Measure the Production of Hadrons At a Testbeam In Chicagoland) is a low-cost, table-top-sized, hadron-production experiment located at the Fermilab Test Beam Facility (FTBF) that will measure hadron scattering and production cross sections that are relevant for neutrino flux predictions. High statistics data will be collected using a minimum bias trigger, enabling measurements of both interacting and non-interacting cross sections. Particle identification will be done using a compact aerogel+heavy gas hybrid ring imaging Cherenkov (RICH) detector, a time-of-flight (ToF) wall, and a lead glass calorimeter array. The ARICH focuses on the kaons, pions and protons separation with multi-track capability up to 8 GeV/c. This presentation is about the implementation of optical reflectors in the ARICH system to reflect Cherenkov light outside of the PMT array acceptance onto the PMT array increasing the angular acceptance of the experiment with a low cost improvement.

CAP Virtual Congress 2021

Optical reflectors in an ARICH detector for a hadron production experiment

cherenkov radiation

mirrors

arich

The 65th Annual Conference on Magnetism and Magnetic Materials (MMM 2020) was held in a virtual form. The COVID-19 pandemic, with its associated uncertainty about international travel and the ability to gather in large groups, meant that the Steering Committee decided to cancel the face-to-face meeting that had been planned in Palm Beach, Florida November 2-6, 2020.

We were reluctant to give up the benefits of meeting face-to-face, and know that shifting to a virtual conference is a significant change for this community. Nevertheless, we are first and foremost concerned about the health and safety of all our Conference participants and their loved ones on returning home after travelling.

The MMM 2020 Steering Committee was working exceptionally hard, along with our sponsors, the IEEE Magnetics Society and AIP Publishing, to make this event serve the needs of our participants, who live in time zones all around the globe, in the best possible way.

You need a ticket to explore this event.

If you have already registered for MMM 2020, and you have already created an account, then you
just need to login (above).

If you have already registered for MMM 2020, but you have not yet created an account, then you
need to click on &quot;create an account&quot; (above) and then login.

Forgot your password? Go to
https://www.underline.io/log-in

If you have not yet registered for MMM 2020 but would like to do so, go to
https://magnetism.org/register

Still need help? Contact our team!


MMM 2020

poster

**WELCOME TO THE 2021 CAP VIRTUAL CONGRESS UNDERLINE PLATFORM**

The CAP staff and our organizing and program committees are pleased to welcome you to our 2021 Congress filled with plenary talks, technical sessions/talks, student presentations and competition sessions, workshops, and several symposia offered by the CAP divisions and its partners.

You will also have opportunities to network with other delegates through the Gathertown platform accessed by selecting the lounge or posters button on the left.

Registered delegates should use the schedule button to call up the details of the session/event they wish to attend.  Each sessions includes a link to access the online platform where the event is taking place, either within Underline or through other Congress-related Zoom meetings.

Invited speaker talks are identified with an (I), and student competitors include a (G*) or (U*) to identify graduate or undergraduate presenters.

Please take the time to check out the information about our sponsors and exhibitors, request further information, or leave a note of thanks for their support.

General information about the Congress can be found on the CAP website Congress pages at https://www.cap.ca/congress/2021.

Looking for a specific talk?   A full searchable list is available on our Indico Congress site at https://indico.cern.ch/event/985448/contributions/

We look forward to sharing this exciting week with you!


An orbital free related density functional theory based on the principles of polymer self-consistent field theory is used to calculate the electron densities, bond energy, bond length and fundamental vibrational frequency of homonuclear diatomic molecules. A simple exchange-correlation functional that neglects correlations is used, and the Pauli potential is based on Edwards–Flory-Huggins interaction taken from polymer physics. Other approximations include a Fermi-Amaldi correction for electron-electron self-interactions and cylindrical averaging to reduce the dimensionality of the problem. Expected bonding characteristics are observed for the first 7 elements in the periodic table. Specifically, quantitatively accurate bond lengths and qualitatively accurate bond energy structure for hydrogen and nitrogen molecules. Bond energy and fundamental vibrational frequency are discrepant up to a factor of two when compared with accepted values. Other elements do not exhibit bonding as expected.

Homonuclear diatomic molecule properties from an orbital-free-related density functional theory

From 2015 to 2018, the Large Hadron Collider (LHC) collided protons at an unprecedented center of mass energy of s=√13 TeV. The ATLAS detector recorded an integrated luminosity of 139fb$^{-1}$ of these collisions. This offers an unprecedented opportunity for physicists to test the Standard Model by measuring predicted but yet unobserved rare processes. The triboson W$\gamma\gamma$ production is one of these unobserved processes. Its sensitivity to the electroweak trilinear and quartic gauge couplings make it a great probe of new physics phenomena as Beyond Standard Model processes could affect the effective strength of these couplings. The dominant source of background to the search for W$\gamma\gamma$ production are jets being misidentified as photons. The advanced data-driven technique used to estimate this background will be presented. Furthermore, preliminary studies of the dominant systematic uncertainties impacting the expected significance of the measurement will be presented.

Study of Wyy tri-boson production in proton-proton collisions with the ATLAS detector

The major ongoing upgrade of the ATLAS detector at the Large Hadron Collider at CERN consists in the replacement of parts of its muon spectrometer. The so-called New Small Wheels (NSWs) will be covered with two detector types that must trigger on and track outgoing particles - one type is small-strip thin gap chambers (sTGCs) assembled into modules of four layers. Canadian-built sTGC modules are characterized at McGill University using cosmic rays before being shipped to CERN for integration into the wheels. To achieve the design tracking performance, misalignments between sTGC layers must be corrected for. The charge profile left by an x-ray gun and coordinate measuring machine (CMM) measurements of quadruplet layers are being used to define these parameters. Work on using cosmic ray data to validate misalignment parameters derived using the above-mentioned methods will be presented.

Validating misalignment measurements between particle detectors for the ATLAS New Small Wheels

MATHUSLA (MAssive Timing Hodoscope for Ultra-Stable neutraL pArticles) is a long-lived particle (LLP) detector which would be constructed on the surface above CMS and is currently in its planning stages. This large-area detector would be composed of several layers of solid plastic scintillator, with wavelength-shifting fibers connected to silicon photomultipliers (SiPMs), allowing us to monitor an empty air-filled decay volume. The purpose of this research is to examine the behavior of a candidate SiPM and signal amplifier for this detection array. The SiPM in question is the SensL MicroFB-30035 and the amplifier is the Broadcom AFBR-S4E001. This goal was accomplished by simulating these components in Ngspice, an electronic circuit simulator. Using this simulation method, we were able to measure the amplified signal output and produce voltage-time plots for it. We will next build this setup in the lab and compare our results to other candidate SiPMs. This research will be useful in developing other aspects of the detection array, the triggering system, and the readout system.

Analyzing the behavior of a Candidate SiPM and Signal Amplifier for MATHUSLA

The NEWS-G experiment uses a spherical proportional counter filled with gas in order to detect potential dark matter particles that can ionize the gas after a nuclear recoil. The detector works by attracting the free electrons towards the center of the sphere where there is a high voltage anode inducing a radial electric field. Near the anode, the accelerated electrons then cause a Townsend avalanche that produces many drifting ions, which creates an identifiable electrical signal. Since this method has been most efficient at energies below 1 GeV, that is where keeping the background contamination at minimum is of upmost importance. However, there is approximately 20 mBq of alpha particles coming from impurities in the copper surface of the sphere that create a sudden influx of events close to the region of interest for up to five seconds. These alphas also lead to fluctuations in the electric field, which in turn alters the time taken for electrons to reach the anode at the center. This presentation aims to show how the consequences of alpha particles in the detector can be characterized, as well as how those consequences can be used to better identify alpha events in order to remove the correlated influx of low energy events.
*On behalf of the NEWS-G collaboration

Analysis and identification of alpha events for NEWS-G

To allow for precision measurements of neutrino interactions in water Cherenkov neutrino detectors, reducing the position uncertainty on the photomultiplier tubes (PMTs) and calibration sources is necessary. This can be achieved with the photogrammetry technique. Detected PMTs in images of the detectors can be used to reconstruct a 3D model of their positions. This photogrammetry technique is being applied in the current Super-Kamiokande (Super-K) detector, and there are plans for its application in the next generation of water Cherenkov detectors, Hyper-K and its intermediate water Cherenkov detector (IWCD).
This talk discusses detection and identification of PMT features from a drone photographic survey of the Super-K detector, and camera calibration and R&D for a built-in photogrammetry camera system in the upcoming IWCD and Hyper-K detectors.

Automated Feature Detection and Camera R&D for Photogrammetry in Super-K and Future Water Cherenkov Neutrino Detectors

The possible existence the magnetic monopole is strongly motivated by theories and extensively tested in experiments. Searches at the LHC have been exclusively conducted with proton-proton collisions. However, the LHC not only collides protons but also heavy ions. Highly relativistic ultraperipheral collisions (UPC), where the ion-ion impact parameter exceeds the ion’s diameter, act as a strong source of electromagnetic radiation. Characterized by minimal hadronic activities, the UPC creates a clean environment to study magnetic monopoles produced via photon-fusion processes. I will present a generator-level study of this production mode, including the modelling of the photon energy spectrum and the monopole interaction required to compute the production cross section at the maximal collision energy of the LHC.

Model of magnetic monopole production in heavy-ion ultraperipheral collisions at the LHC

SNO+ is a neutrino detector located 2 km underground at the deep clean lab facility - SNOLAB, in Vale’s Creighton Mine, in Sudbury ON. The primary goal of the SNO+ experiment is to search for an extremely rare, hypothesized phenomenon, neutrino-less double beta decay (0vbb) - the discovery of which will have a multitude of major implications in fundamental physics. Given the rarity of this phenomenon, it is paramount that all backgrounds in the detector be carefully measured and understood. In this poster, I will show the importance of background analysis and detail the method used to find a rate for K40 backgrounds – a signal that is especially difficult to measure. The techniques used in this analysis allowed for the first-ever estimate of the K40 background made directly from data taken with a detector partially filled with liquid organic scintillator.

K40 Backgrounds in the SNO+ Neutrino Detector

ABSTRACT:
SNO+ is large multipurpose detector located at SNOLAB, Canada, Sudbury filled with liquid scintillator. The scintillator will eventually be loaded with a tellurium isotope, allowing to look for neutrino-less double beta decay which is extremely rare. This will determine if the neutrino is its own antiparticle. One of the main concerns for these rare event experiments is the presence of backgrounds, which could mask the signals of interest. This presentation will focus on Rn222, one of the most common backgrounds due to its excessive prevalence in the mine environment. Radon decays into daughters where the energies lie within the region of interest for neutrino-less double beta decay. The detector is housed in a large cavity that is filled with ultrapure water and has a nitrogen cover-gas in order to avoid contamination. This presentation will focus on radon assays, a technique that was developed for the SNO experiment. Assays are performed frequently at different positions to monitor the radon levels. During a radon assay, radon is trapped with a ZnS coated lucas cell for a period of time and known amount of flow. This lucas cell can then be connected to a PMT, which detects the decayed alphas that are used to calculate the number of radon atoms in the cavity. This external technique is a crucial part of measuring and monitoring the low background for the experiment.

SN0+ U-238 External Background Measurements using Radon Assay Technique

Cherenkov radiation plays a crucial role in particle physics experiments.
This is of particular importance in water-filled neutrino detectors, where electron neutrinos are observed through the Cherenkov radiation of ultra-relativistic secondary particles created in the detector's volume. Modern simulation methods of the process that describe Cherenkov emission assume coherence of the radiation throughout the particle’s path without accounting for the impact of scattering of the electrons in matter. Here we consider a more physically accurate calculation of Cherenkov radiation as a phenomenon of wave interference. We then apply this calculation to a simulation that accounts for single Coulomb scattering of the electron with the material.
The obtained angular distributions of the photons as they would be observed in a detector are compared to the ones predicted by standard simulation tools.
