In this work, we present an alternative methodology to solve the particle-fluid interaction in the
resolved CFDEM
R coupling framework. This numerical approach consists of coupling a Discrete Element
Method (DEM) with a Computational Fluid Dynamics (CFD) scheme, solving the motion of immersed particles
in a fluid phase. As a novelty, our approach explicitly accounts for the body force acting on the fluid phase when
computing the local momentum balance equations. Accordingly, we implement a fluid-particle interaction
computing the buoyant and drag forces as a function of local shear strain and pressure gradient. As a benchmark,
we study the Stokesian limit of a single particle. The validation is performed comparing our outcomes with the
ones provided by a previous resolved methodology and the analytical prediction. In general, we find that the
new implementation reproduces with very good accuracy the Stokesian dynamics. Complementarily, we study
the settling terminal velocity of a sphere under confined conditions.

Powders &amp; Grains 2021

Modeling particle-fluid interaction in a coupled CFD-DEM framework
