DEM modeling of segregation and stratification in pouring heaps of bidispersed mixtures of rounded particles

United States

This study aims to assess and analyse the patterns of segregation and stratification in pouring heaps of granular mixtures composed by binary sized and uniformly shaped particles. We present 2D and 3D simulations which respectively build deposits of poured disks and spheres by means of a discrete-element approach known as contact dynamics (CD). In order to identify preferable conditions for segregation and stratification, we try several deposition scenarios varying the pouring flow rate, injection height, heap’s width and mass ratio between large and small grains in our binary samples. Although some authors assert that shape dispersity might not be necessary to obtain stratification, the phenomenon seems hard to seize with mono-shaped granular media as it appears to require a close control on pouring conditions. The introduction of our DEM models and statistical analysis intend to provide examples of what could constitute efficient numerical tools to study the remaining open problems related to heap segregation patterns prediction.
