Delivering quantum optical technologies at scale will also require the scaling and integration of classical readout and control hardware. To date, silicon quantum photonics has not fully harnessed the performance of the complimentary metal-oxide-semiconductor (CMOS) electronics industry and typically relies on discrete, PCB scale, packaged hardware. We report an integrated homodyne detector consisting of a silicon photonic integrated circuit wirebonded directly to a dedicated silicon-germanium transimpedance amplifier die. We measure a bandwidth of 1.7 GHz, 84% efficiency for on-chip states, shot noise clearance across 9 GHz with a device footprint of 0.84 mm2. Using a fibre coupled PPLN source, we measure up to 0.89 dB of quadrature squeezing on-chip and characterise the squeezing across the entire 9 GHz bandwidth available. In addition, we present some new results further demonstrating the performance advances available from photonic-electronic integration.
