Artificial neural networks employing the biomimetic functions of memristors and crossbar array architecture have been actively explored and designed for use in energy‐efficient neuromorphic computing. In particular, a memristor with a crossbar array architecture is more efficiently able to perform vector-matrix multiplication compared to conventional CMOS hardware. In this process, a memristor with certain characteristics is required, such as ohmic behavior in all resistance states and symmetry/linearity in its long-term potentiation/depression behavior. In this study, to improve these characteristics, we proposed and demonstrated a Li-based composite memristor (LCM) that consists of three phases: Li-doped TiO2 as a Li reservoir, Li4Ti5O12 as the insulating phase, and Li7Ti5O12, as the metallic phase. In the LCM, resistance switching property was induced by adjusting the ratio of the metallic to the insulating phase. The phase formation and coexistence of TiO2, Li4Ti5O12, and Li7Ti5O12 were confirmed using X-ray diffraction patterns and Raman spectral analysis. The proposed LCM exhibited symmetric and gradual switching behavior for both set and reset switching in a full I-V sweep because the driving force leading to the increase/decrease in the ratio of the metallic phase inside the thin film during set and reset switching was the same. The proposed LCM was thus demonstrated to be promising for improving both the ohmic behavior of synapse devices and the linearity and symmetry of long-term potentiation/depression behavior required for artificial neural networks.
Acknowledgments: This work was supported by the National Research Foundation of Korea(NRF) grant funded by the Korea government(MSIT) (2019R1F1A1059637) and the Ministry of Trade, Industry &amp; Energy (MOTIE, Korea) under the Industrial Strategic Technology Development Program. No. 10068075, &#39;Development of Mott-transition-based forming-less non-volatile resistive switching memory &amp; array&#39;.


Materials Challenges for Memory

Li-Based Composite Memristor for Artificial Neural Networks

lithium titanate

phase transition

composite memristor

lithium-based memristor

artificial neural networks
